Specifications
Brand Name :
iqualitrol
Model Number :
iGrind-811
MOQ :
1 Set
Payment Terms :
T/T
Supply Ability :
30 Sets per Month
Delivery Time :
10 Working Days
Packaging Details :
Plywood Pallet
Diameter :
203mm (Opt. 250mm)
Speed :
0–1400rpm, stepless speed
Power :
750W
Voltage :
AC220V/50Hz/1Ph
Description

Single Disc Diameter

203mm Stepless Speed Sample Polishing Machine with Water Cooling

Brief Introduction:

The iGrind-811 metallographic sample grinding and polishing machine is a single-disc benchtop unit with freely selectable rotation direction for the grinding and polishing discs.

Equipped with a microprocessor control system, it allows independent operation of the grinding and polishing processes by simply changing the metallographic abrasive papers and polishing cloths, thereby enhancing its versatility.

The machine features smooth rotation, high safety and reliability, a compact design, and low noise; it is also fitted with a water-cooling system that cools the specimen during grinding to prevent overheating and subsequent damage to the metallographic structure.

iGrind-811 is an ideal sample-preparation instrument for industrial enterprises, research institutions, and laboratory settings in colleges and universities.

Technical Specifications:

Grinding and polishing disc diameter φ203mm
Polishing pad rotational speed 0–1400 r/min (stepless speed variation)
Grinding and polishing pad steering Adjustable clockwise and counterclockwise
Machine power Single-phase AC 220V 50Hz
Input Power 0.75KW
External dimensions 595×785×320mm
Net weight 40kg
