sms monitor temperature, Temperature logger gsm sms temperature monitoring alarm

System Feature

• Industrial NXP 32-bit ARM MCU
• Reliable performance with built-in double watchdog, 24×7 operation
• Dual digital filters for anti-noise
• Support automatic network reconnection and data re-send
• Synchronize clock with multiple way, Sms, NTP, CwtIO Server
• Configurable action schedule(second, minute, day, week, month)
• Event-based linkage programming, e.g. alarm linkage output
• Easy used GUI configure software for setting up to 100 parameters
• Optional exterior rechargable battery for 8-20 hours working when power lost

DI feature

• Monitor dry contact(NO or NC)

DO(T) feature

• Relay drivable output(drive voltage=power supply voltage, Drive current≤500mA)
• Remote or local event activate DO on/off/pulse
• Remember status when power lost

DO(K) feature

• Relay output(NO, contact load: 2A / 125VAC,220VDC)
• Remote or local event activate DO on/off/pulse
• Remember status when power lost

AI feature

• Accept 4-20mA (option: 0-5V), Sampling frequency: 33Hz, 10-bit precision)
• Convert signal to actual measure value,support adjustment
• Can set parameters for value processing, alarm, data transmission
• Detect connect or disconnect to alarm

SMS feature

• Support 10 cell phone numbers for alarm and control
• Sms alarm when any IO channel triggered or out of preset normal range
• Customizable sms messages, like alarm, receove, report
• Query any IO channel’s status or value via sms command
• Activate output by sending sms
• Configurable schedule for sms report IO channel's status or value
• Sending sms command to update setting
• Forward simcard overdue sms to admin
• Support power lost sms alarm and recover sms(works with inside battery)

Wireless network communication

• Optianal onboard GPRS, 3g, 4g, Wi-Fi module
• Support TCP/IP two-way communication with Max.4 servers(IP or domain)
• Support post or respond mode for data communication
• Communication protocol: Modbus TCP,http post, Cwt_IO(two-way communication)
• Support two-way data transparent transmission with RS485 or RS232

Modbus feature

• Can work as a modbus master to poll salve over RS485
• As a RS485 I O module to be polled by modbus master
• Run Modbus RTU or TCP protocol over GPRS/3G

TI feature

• Configurable parameters for alarm (high or lower), record, data communication, adjustment
• Can switch Fahrenheit or centigrade
• Alarm when probe connection lost
