High Accuracy Compact Size Low Power Consumption Inertial Measurement Unit (IMU) for Navigation and Robotics
High Accuracy Compact Size Low Power Consumption Inertial Measurement Unit (IMU) for Navigation and Robotics
High Accuracy Compact Size Low Power Consumption Inertial Measurement Unit (IMU) for Navigation and Robotics
High Accuracy Compact Size Low Power Consumption Inertial Measurement Unit (IMU) for Navigation and Robotics
Specifications
Brand Name :
Navioptics
Model Number :
F61IMU
Certification :
CCS
Place of Origin :
China
MOQ :
one set
Payment Terms :
T/T
Supply Ability :
30 set per month
Delivery Time :
15 Days
Packaging Details :
carton box
Display Type :
Color LCD
Power Usage :
15 VDC CAN bus
Zero Bias Repeatability :
0.005°/h
Outputdata :
Angular velocity, Linear acceleration, Magnetic field
Updaterate :
Up to 1 kHz
Type :
Sensor
Accuracy :
±0.1°/s (gyroscope), ±0.01g (accelerometer)
Applications :
Navigation, Robotics, Drones, Automotive, VR/AR
Dimensions :
Varies by model, typically 20mm x 20mm x 10mm
Powersupplyvoltage :
3.3V or 5V
Weight :
Typically less than 10 grams
Outputformat :
Digital (16-bit or 32-bit data)
Input Range :
400°/s
Calibration :
Factory calibrated, supports in-field calibration
Random Walk Coefficient :
0.01°/√h
Operatingtemperaturerange :
-40°C to +85°C
Components :
Accelerometer, Gyroscope, Magnetometer (optional)
Description

Introduction

The Inertial Measurement Unit (IMU) features advantages such as compact size, light weight, low power consumption, and high precision. It can be used to design pure strapdown, single-axis, and dual-axis modulated inertial navigation systems, meeting the demand for small-size, high-precision inertial navigation equipment in new unmanned platforms, underwater/torpedo weaponry, as well as land-based and airborne weapon platforms. It possesses the capability for dynamic measurement of carrier angular and linear motion information.

Technical Parameters

Item

Indicator

Description

Parameter

Remark

Gyro

Zero Bias

Bias Stability (100s)

0.03°/h

Zero Bias Stability at Variable Temperature (100s)

0.1°/h

Temperature Variation Rate 1℃/min(-40℃~60℃)

Scaling Factor

Scale Factor Nonlinearity

≤20ppm

Other Indicators

Random Walk Coefficient

0.005°/½h

Input Range

400°/s

Accelerometer

Deviation

Zero Bias Repeatability

50μg

Zero Bias

Bias Temperature Sensitivity

50μg/℃

Scaling Factor

Scale Factor Repeatability

50ppm

Scale Factor Temperature Sensitivity

50ppm/℃

Range Indicators

Input Range

±20g

Characteristics

Environmental Performance

Operating Temperature

-40℃～60℃

Storage Temperature

-45℃～70℃

General Requirements

Power Supply

18～36V(DC)

Stable Power Consumption

≤16W

Startup Power Consumption ≤20W

Mounting Hole Diameter

4-Φ4.5mm

Dimensions(mm)

110×110×100

Weight
