1. Core Functionality

• High-speed Performance: Boasts a unity-gain bandwidth of 180 MHz and a slew rate of 800 V/μs, enabling accurate amplification of fast-changing signals (e.g., high-frequency analog waveforms, video signals).
• Low-power Characteristic: Draws a maximum supply current of only 4.5 mA per channel, making it ideal for power-constrained systems.
• Wide Operating Voltage Range: Supports both single-supply (2.7 V to 12 V) and dual-supply (±1.35 V to ±6 V) operation, offering flexible system integration capability.
• Precision Parameter Specifications: Features a maximum input offset voltage of 3 mV, a maximum input bias current of 1 μA, and a minimum open-loop gain of 80 dB, ensuring signal integrity and linearity.
• Rail-to-Rail Output: Under light-load conditions, the output swing can reach within 100 mV of the supply rails, maximizing the signal dynamic range in low-voltage applications.

2. Typical Applications

• Video Systems: Composite video signal amplification, video distribution, and signal conditioning for CCD/CMOS image sensors (e.g., security cameras, industrial vision systems).
• Communication Equipment: RF signal baseband amplification, IF stage filtering, and data converter (ADC/DAC) interface circuits (e.g., wireless transceivers, satellite communication modules).
• Test & Measurement Instruments: Oscilloscope input amplifiers, function generator output stages, and precision data acquisition systems (DAQ).
• Consumer Electronics: High-definition (HD) display drivers, audio/video receivers (AVR), and signal processing in portable devices (e.g., smartphones, tablets).
• Industrial Control: Sensor signal amplification (e.g., pressure, temperature sensors), motor control feedback circuits, and industrial automation signal conditioning.

Key Specifications Summary

• Unity-Gain Bandwidth: 180 MHz
• Slew Rate: 800 V/μs
• Supply Voltage: 2.7 V to 12 V (single-supply); ±1.35 V to ±6 V (dual-supply)
• Quiescent Current: 4.5 mA (max)
• Input Offset Voltage: 3 mV (max)
• Output Swing: ±(V_S - 0.1 V) (at 1 kΩ load)
• Package Type: 8-Lead Thin Shrink Small Outline Package (TSSOP, ARTZ suffix), Reel Packaging (REEL7)
