Original Electronic Spare Parts Integrated Circuit IR2183STRPBF IC Chips
Original Electronic Spare Parts Integrated Circuit IR2183STRPBF IC Chips
Specifications
Brand Name :
Infineon Technologies
Model Number :
IR2183STRPBF
Certification :
RoHS Compliant
Place of Origin :
Original
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300000/pcs/week
Delivery Time :
1-3day
Packaging Details :
Original
Description :
Gate Drivers Hlf Brdg Drvr Soft Trn On 500ns
Stock :
300000
Shipping Method :
Express
Input Type :
Standard
Voltage Supply - Internal :
Standard
Condition :
100% Original
Package :
Tray, Reel, Packing foam, Box
Lead time :
1-3days
Quality :
High-quality
Express :
fedex, tnt. dhl. ems. ups.
Description

Original Electronic Spare Parts Integrated Circuit IR2183STRPBF IC Chips

The IR2183(4)(S) are high voltage, high speed power MOSFET and IGBT drivers with dependent high and low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable rugge dized monolithic construction. The logic input is compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which operates up to 600 volts.

Specifications
Product Attribute Attribute Value
Manufacturer: Infineon
Product Category: Gate Drivers
RoHS: Details
Product: IGBT, MOSFET Gate Drivers
Type: Half-Bridge
Mounting Style: SMD/SMT
Package / Case: SOIC-8
Number of Drivers: 2 Driver
Number of Outputs: 2 Output
Output Current: 1.9 A
Supply Voltage - Min: 10 V
Supply Voltage - Max: 20 V
Rise Time: 40 ns
Fall Time: 20 ns
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Packaging: Reel
Packaging: Cut Tape
Brand: Infineon Technologies
Features: Synchronous
Height: 1.5 mm
Length: 5 mm
Logic Type: CMOS, TTL
Maximum Turn-Off Delay Time: 220 ns
Maximum Turn-On Delay Time: 180 ns
Moisture Sensitive: Yes
Operating Supply Current: 1.6 mA
Pd - Power Dissipation: 625 mW
Product Type: Gate Drivers
Propagation Delay - Max: 330 ns
Subcategory: PMIC - Power Management ICs
Technology: Si
Width: 4 mm
Part # Aliases: IR2183STRPBF SP001538442
Unit Weight: 0.019048 oz


Original Electronic Spare Parts Integrated Circuit IR2183STRPBF IC ChipsOriginal Electronic Spare Parts Integrated Circuit IR2183STRPBF IC ChipsOriginal Electronic Spare Parts Integrated Circuit IR2183STRPBF IC Chips

P/N Manufacturer Packaging Date Code Qty
Z0805C102A Amphenol N/A 23+ 125000
ZM4752A-GS08 Amphenol N/A 22+ 75800
Z8023016P Amphenol N/A 22+ 129800
ZHB6792T Amphenol N/A 21+ 75000
Z86E3116P Amphenol N/A 21+ 65000
Z25YLT52R Amphenol N/A 21+ 200000
ZMY18-GS08 Amphenol N/A 23+ 125000
Z16FMC28AG20E Amphenol N/A 23+ 75800
ZMY100-GS08 Amphenol N/A 22+ 129800
Z-15GQ55 Amphenol N/A 22+ 45000
Z25M561S Amphenol N/A 21+ 125000
Z25M102S Amphenol N/A 23+ 75000
Z16CT52R Amphenol N/A 23+ 65000
ZB4BZ1025 Amphenol N/A 22+ 200000
ZMY4V7-GS08 Amphenol N/A 22+ 125000
ZM10E10F01 Amphenol N/A 21+ 75800
ZTB614.4P Amphenol N/A 21+ 129800
ZB6Y2308 Amphenol N/A 23+ 75000
ZN01-025-0010- Amphenol N/A 21+ 65000
Z84C2008P Amphenol N/A 23+ 200000
ZM331643G Amphenol N/A 23+ 125000
Z0103MARL1G Amphenol N/A 22+ 75800
Z8F1621VN020E Amphenol N/A 22+ 129800
ZB5AV063 Amphenol N/A 21+ 45000
ZX62D1-B-5P Amphenol N/A 23+ 125000
ZMCHM9L3L Amphenol N/A 23+ 125000
Z84C9008V Amphenol N/A 22+ 75800
Z8F1680AN020S Amphenol N/A 22+ 129800
ZTA7.3728M Amphenol N/A 21+ 75000
ZB4BZ1015 Amphenol N/A 21+ 65000
ZM4736A-GS08 Amphenol N/A 21+ 200000
Z8F6422VS020S Amphenol N/A 21+ 125000
ZB4BZ105 Amphenol N/A 21+ 75800
Z4KE140A-E3/54 Amphenol N/A 23+ 129800
ZMA00A150S06P Amphenol N/A 23+ 45000

Original Electronic Spare Parts Integrated Circuit IR2183STRPBF IC Chips
Q1:Who are you?

A1: We are a distributor of electronic components. Our products include IC. inductor, resistor, potentiometer, capacitor and module, etc.Everything you can think of about electronic components!
Q2:Are you products original?
A2: Yes all products are original and produced by original manufacturers.
Q3:When will you ship?
A3:This depends on the quantity of the goods you ordered, we have stock, usually 15-20 days delivery time.
Q4:What is your warranty?
A4:365 days after goods have been received. Our products will be 100% tested before they are sent out.
