HMC1501 Sensor IC 6.5kOhms Magnetic Displacement Sensors SOIC8 Magnetic Linear Sensor​

Product Overviews Of HMC1501

HMC1501 is miniature surface mount sensors for linear, angular, or rotary displacement designed for magnetic saturating field sensing.
HMC1501 contains a single saturated-mode Wheatstone bridge sense element that creates an output voltage with respect to the direction of the magnetic flux passing over the sensor surface.

Specification Of HMC1501

Features Of HMC1501

Wide Angular Range
– Angular range of ±45° with <0.07° resolution
Effective Linear Range
- >8mm when two sensors are mounted on two ends.
- Additional range can be added through multiple sensor arrays
Absolute Sensing
- No indexing with exact position known
Low Noise Passive Element Design
Surface Mount Sensors
- RoHS Compatible and suitable for High Speed SMT Assembly
Low Voltage Operations (2.0V)
- Compatible for Battery Powered Applications
