LAN8720A-CP-TR Ethernet IC RMII 10/100 Ethernet Transceiver With HP Auto-MDIX Support

Product Description Of LAN8720A-CP-TR
LAN8720A-CP-TR is a low-power 10BASE-T/100BASE-TX physical layer (PHY) transceiver with variable I/O voltage that is compliant with the IEEE 802.3-2005 standards.

Specifications Of LAN8720A-CP-TR

Highlights Of LAN8720A-CP-TR
Single-Chip Ethernet Physical Layer Transceiver (PHY)
Comprehensive flexPWR® Technology
Flexible Power Management Architecture
LVCMOS Variable I/O voltage range: +1.6V to +3.6V
Integrated 1.2V regulator
HP Auto-MDIX support
Miniature 24-pin QFN/SQFN lead-free RoHS compliant packages (4 x 4mm).

Features Of LAN8720A-CP-TR
High-Performance 10/100 Ethernet Transceiver
Compliant with IEEE802.3/802.3u (Fast Ethernet)
Compliant with ISO 802-3/IEEE 802.3 (10BASE-T)
Loop-back modes
Auto-negotiation
Automatic polarity detection and correction
Link status change wake-up detection
Vendor specific register functions
Supports the reduced pin count RMII interface
Power and I/Os
Various low power modes
Integrated power-on reset circuit
Two status LED outputs
Latch-Up Performance Exceeds 150mA per EIA/JESD 78, Class II
May be used with a single 3.3V supply
Additional Features
Ability to use a low cost 25Mhz crystal for reduced BOM
Packaging
24-pin QFN/SQFN (4x4 mm) Lead-Free RoHS Compliant package with RMII
Environmental
Extended commercial temperature range (0°C to +85°C)
Industrial temperature range version available (-40°C to +85°C)

Applications Of LAN8720A-CP-TR
Set-Top Boxes
Networked Printers and Servers
Test Instrumentation
LAN on Motherboard
Embedded Telecom Applications
Video Record/Playback Systems
Cable Modems/Routers
DSL Modems/Routers
Digital Video Recorders
IP and Video Phones
Wireless Access Points
Digital Televisions
Digital Media Adapters/Servers
Gaming Consoles
POE Applications
