LAN7801T-V/9JXVAO Ethernet IC SuperSpeed USB 3.1 Gen 1 to 10/100/1000 Ethernet Controller With RGMII

Product Description Of LAN7801T-V/9JXVAO
LAN7801T-V/9JXVAO is a high performance USB 3.1 Gen 1 to 10/100/1000 Ethernet controller with RGMII. With applications ranging from automotive infotainment/ADAS, notebook/tablet docking stations, set-top boxes, and PVRs, to USB port replicators, USB to Ethernet dongles, embedded systems, and test instrumentation, the LAN7801 is a high performance and cost effective USB to Ethernet connectivity solution.

Highlights Of LAN7801T-V/9JXVAO
Single Chip SuperSpeed (SS) USB 3.1 Gen 1 to 10/100/1000 Ethernet Controller
RGMII output to external Gigabit PHYs
Integrated 10/100/1000 Ethernet MAC (Full-Duplex Support)
Integrated USB 3.1 Gen 1 SS Device Controller and PHY
Low Power Consumption
Compliant with Energy Efficient Ethernet IEEE 802.3az
Wake on LAN support (WoL)
Configuration via One Time Programmable (OTP) Memory
NetDetach provides automatic USB attach/detach when Ethernet cable is connected/removed
AEC-Q100 qualified for automotive applications

Features Of LAN7801T-V/9JXVAO
USB 3.1 Gen 1 Device Controller
Supports SS (5 Gbps), HS (480 Mbps), and FS (12 Mbps) modes
Four endpoints supported
Supports vendor specific commands
Remote wakeup supported
10/100/1000 Ethernet Controller
Compliant with IEEE802.3/802.3u/802.3ab/802.3az
10BASE-T/100BASE-TX/1000BASE-T support
Full- and half-duplex capability (only full-duplex operation at 1000 Mbps)
Controller Modes
Microsoft AOAC support (Always On Always Connected)
Supports Microsoft NDIS 6.2 large send offload
Full-duplex flow control
Loop-back modes
Supports IEEE 802.1q VLAN tagging
VLAN tag based packet filtering (all 4096 tags)
Flexible address filtering modes
33 exact matches (unicast or multicast)
512-bit hash filter for multicast frames
Pass all multicast
Promiscuous unicast/multicast modes
Inverse filtering
Pass all incoming with status report
Supports various statistical counters
PME pin support
Frame Features
Supports 32 wake-up frame patterns
Preamble generation and removal
Automatic 32-bit CRC generation and checking
9 KB jumbo frame support
Automatic payload padding and pad removal
Supports Rx/Tx checksum offloads (IPv4, IPv6, TCP, UDP, IGMP, ICMP)
Ability to add and strip IEEE 802.1q VLAN tags

Applications Of LAN7801T-V/9JXVAO
Automotive Infotainment
Notebook/Tablet Docking Stations
Detachable Laptops
USB Port Replicators
Standalone USB to Ethernet Dongles
Embedded Systems / CE Devices
Set-Top Boxes / Video Recorders
Test Instrumentation / Industrial
