Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks
Specifications
Brand Name :
SUNWOOL
Model Number :
Mullite Insulation Brick
Certification :
ISO CE
Place of Origin :
China
MOQ :
500 pcs
Price :
0.6usd -1.5usd
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
10000 pallets/month
Delivery Time :
10 days
Packaging Details :
pallets
Alkali Resistance :
Good
Wokring Tempature :
1260-1760℃
Material :
Mullite
Dimensions :
Customizable
Refractoriness :
900-1500C
Size :
230*114*65mm 230*114*75mm
Density :
0.5-1.3g/cm3
Package :
Pallet
Shape :
Customizable
Color :
White or Pink
Description
Mullite Insulation Brick Lightweight High Temperature Resistance for Industrial Kilns
Product Overview:

Our Mullite Insulation Brick is a premium quality refractory product manufactured from carefully selected high-purity clays and ceramic materials. Designed with a uniform pore structure and excellent thermal insulation properties, it provides reliable performance in applications up to 1760°C while significantly reducing energy consumption and heat storage.

Technical data
Item JM23 JM26 JM28 JM30
AL2O3(%) 38-44 50-58 65-70 70-73
Fe2O3(%) 1.0 0.9 0.8 0.7
Classification Temperature (℃) 1350 1430 1540 1600
Bulk Density (g/cm3) 0.6-1.0 0.8-1.0 0.9-1.0 1.0-1.3
Reheating Linear Change (%)
CT-30 ℃X 8H		 1250℃
-0.5		 1400℃
-0.5		 1500℃
-0.5		 1550℃
-0.5
Cold Crushing Strength (Mpa) 3.0-4.5 3.0-4.5 3.0-4.5 3.0-4.5
Modulus of Rupture (Mpa) 1.5 2.0 2.5 3.0
Thermal conductivity 400℃(W/m.k) 0.25 0.27 0.32 0.41
Thermal Expansion1000℃(%) 0.5 0.7 0.8 0.9
Key Features:
  • Excellent Thermal Insulation: Low thermal conductivity minimizes heat loss and improves furnace efficiency
  • High Temperature Stability: Maintains structural integrity under continuous high temperature operation
  • Lightweight Construction: Reduced bulk density lowers structural load and heat storage capacity
  • Low Impurity Content: Minimal iron oxide and alkali components enhance corrosion resistance
  • Precise Dimensional Control: Machined to close tolerances for easy installation and tight joints

Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks

Technical Advantages:
  • Working temperature range: 1260°C to 1760°C depending on grade
  • Bulk density: 0.6-1.3 g/cm³ across different specifications
  • Good compressive strength and thermal shock resistance
  • Low linear shrinkage after prolonged heating
  • Uniform pore structure for consistent insulation performance

Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks

Applications:
  • Primary hot face linings in industrial furnaces
  • Backup insulation for kilns and reactors
  • Flue and duct insulation systems
  • Heat treatment and annealing equipment
  • High temperature pipe and vessel insulation
Performance Benefits:
  • Energy Saving: Reduces fuel consumption through superior insulation
  • Fast Thermal Cycling: Low heat storage enables quicker heating and cooling cycles
  • Long Service Life: Resistant to thermal shock and chemical attack
  • Easy Installation: Lightweight and precise dimensions simplify construction
Quality Assurance:

Manufactured under strict quality control with ISO-certified processes, our mullite insulation bricks undergo rigorous testing for density, strength, and thermal properties to ensure consistent performance in demanding applications.

Lightweight Mullite Refractory Bricks Industrial Kiln High Temperature Insulation Bricks

Support Services:
  • Technical consultation for proper grade selection
  • Custom cutting and shaping available
  • Installation guidance and thermal calculation support
  • Worldwide shipping with protective packaging
