Lining Unshaped Conventional Dense Refractory Castable For Furnace
Lining Unshaped Conventional Dense Refractory Castable For Furnace
Lining Unshaped Conventional Dense Refractory Castable For Furnace
Lining Unshaped Conventional Dense Refractory Castable For Furnace
Lining Unshaped Conventional Dense Refractory Castable For Furnace
Lining Unshaped Conventional Dense Refractory Castable For Furnace
Specifications
Brand Name :
Leadsun
Model Number :
Refractory Castable
Certification :
ISO CE
Place of Origin :
China
MOQ :
1 Ton
Price :
200 usd - 500usd
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
1000 tons/month
Delivery Time :
10 days
Packaging Details :
1000 tons/month
Usage :
Furnace Liner,Fire Resistance Place,working lining casting,kiln hood,Refractory Raw Material
Name :
Refractory Castables,high alumina self flowing refractory castable,Insulating castable refractories for nonferrous metal furnace
Refractoriness :
1350-1850C
Size :
1-6mm
Package :
bag+ pallet
Al2O3 :
40-90%
Color :
Grey
Type :
low cement, high alumina, insulation type,plastic,gunning type
Description

Lining Unshaped Conventional Dense Refractory Castable For Furnace

Conventional dense castable is produced from premium bauxite and flint clay aggregates, silica powder and α-alumina micropowder, bonded with calcium aluminate refractory cement. Different formulations are developed to suit a wide range of industrial furnace applications. TSCD series products are particularly suitable for steelmaking furnaces, boilers, incinerators, and other high-temperature industrial equipment.

Technical data

Item

LDSCD45

LDSCD55

LDSCD60

LDSCD65

Service Temp ℃

1400

1450

1500

1550

Bulk Density (g/cm3)

(Dried at 110℃)

2.2

2.2

2.3

2.35

CCS 110℃

(Mpa) 1100℃ 1500℃

45

40

-

47

42

-

50

45

65

50

45

68

MOR 110℃

(Mpa) 1100℃

1500℃

7

6

-

7

6

-

8

7

9

8

7

9

Max Grain Size (mm)

6

6

6

6

Chemical Analysis(%)

Al2O3

Fe2O3

45

2.0

50

2.5

60

2.5

65

2.3

Application Guidelines

Mixer

Placement

Water/Mixer Temp℃

Mixing Time(Min):Dry/Wet

P

R/V/T

20±5

2/5

P

R/V/T

20±5

2/5

P

R/V/T

20±5

2/5

P

R/V/T

20±5

2/5

Water % (Typical)

11-13

11-13

9-11

9-11

Features

  • Excellent abrasion resistance, suitable for high-wear operating conditions

  • Good thermal shock resistance, maintaining stability under rapid temperature changes

  • High temperature resistance, ensuring reliable performance in severe thermal environments

  • Strong corrosion resistance, protecting against chemical and slag attack

Applications

  • Boiler refractory linings, including CFB boilers, chain grate boilers, and other industrial boilers

  • Steel industry applications, such as furnaces, ladles, and high-temperature processing equipment
