High Aluminium Insulation Castable 1700C - 2000C Refractory High Temperature Cement Castable
High Aluminium Insulation Castable 1700C - 2000C Refractory High Temperature Cement Castable
High Aluminium Insulation Castable 1700C - 2000C Refractory High Temperature Cement Castable
High Aluminium Insulation Castable 1700C - 2000C Refractory High Temperature Cement Castable
High Aluminium Insulation Castable 1700C - 2000C Refractory High Temperature Cement Castable
High Aluminium Insulation Castable 1700C - 2000C Refractory High Temperature Cement Castable
Specifications
Brand Name :
LEADSUN
Model Number :
Insulation Castable
Certification :
CE ISO
Place of Origin :
China
MOQ :
1ton
Price :
Negotiable
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
1000 tons/month
Delivery Time :
7-10 days
Packaging Details :
Kraft paper bag + Pallet
Refractoriness :
1350-1850C
Size :
1-6mm
Package :
bag+ pallet
Al2O3 :
40-90%
Color :
Grey
Type :
low cement, high alumina, insulation type,plastic,gunning type
Description

Insulating castable refers to a specific family of refractory castable (refractory concrete). Insulating castable is designed to display low density and low thermal conductivity to keep heat energy and to reduce fossil energy consumption.

These castables are a specialised form of refractories that are predominantly used on the cold-face applications (temperature ranging from 900°C to 1500°C). Their main function is to provide thermal insulation, and their typical design nature is low density and thermal conductivity.

This castable is premixed combinations of refractory aggregates, matrix components or modifiers, bonding agents, and admixtures

Advantage

Insulating castable has strong permeability, which is easy for the forming of dense and improve the air tightness. Insulation castable material can be used in petroleum, construction, steel industrial and other industries.

Insulating castable refractory materials are key to this energy-saving process due to their inherent low heat conductivity as well as advantages derived from ease of placement and structural strength.

Item LDSIN08 LDSIN12 LDSIN14 LDSIN15
Service Temp ℃

800

1100

1400

1700
Bulk Density (g/cm3)
(Dried at 110℃)

0.8

1.2

1.4

1.5
CCS 110℃
(Mpa) 1100℃

10

/

15

10

25

20

35

30
MOR 110℃
(Mpa) 1100℃

3

/

4

3

5

4

6

5
Max Grain Size (mm)

6

6

6

6
Chemical Analysis(%)
Al2O3
Fe2O3


25

3.5


30

2.8


45

1.5


83

1.0
Application Guidelines
Mixer
Placement
Water/Mixer Temp℃
Mixing Time(Min):Dry/Wet


P

V

20±5

1/3


P

V

20±5

1/3


P

V

20±5

1/3


P

V

20±5

1/3
