Quick Detail:
Leadsun Glass Wool Board is manufactured using advanced centrifugal technology and environmentally friendly thermosetting resin binders. Composed of ultra-fine glass fibers with diameters of only a few microns, it contains numerous tiny air pockets that provide exceptional thermal insulation, sound absorption, and fire safety properties. This makes it an ideal insulation material for a wide range of construction and industrial applications.
Specifications:
| item |
unit |
index |
Standard |
| Density |
kg/m3 |
50-130 |
GB/T 11835-2016 |
| Thickness |
mm |
50-150 |
GB/T 11835-2016 |
| Size |
mm |
1200*600 |
GB/T 11835-2016 |
| Thermal conductivity |
W/m.k |
≤0.043 |
GB/T 11835-2016 |
| Grade of combustibility |
|
A1 |
GB 8624 |
| Surface combustion characteristics |
|
FSI=0,SDI=5 |
ASTM E84 |
| Max service temperature |
℃ |
≥600 |
GB/T 11835 |
| Shot content |
Kg/m² |
≤0.5 |
GB/T 11835-2016 |
| Moisture rate |
% |
≤0.5 |
GB/T 11835-2016 |
| Water content |
% |
≥98 |
GB/T 11835-2016 |
| Acidity coefficient |
|
≥1.6 |
GB/T 11835-2016 |
| Slag inclusion content |
% |
≤7.0 |
GB/T 11835-2016 |
| Average fiber diameter |
um |
≤6.0 |
GB/T 11835-2016 |
| Organic mater content |
% |
≤4.0 |
GB/T 11835 |
Features:
- Excellent Thermal Insulation: Low thermal conductivity (≤0.043 W/m·K) ensures effective heat retention and energy efficiency.
- Superior Acoustic Performance: Effectively absorbs sound, reducing noise transmission in buildings and equipment.
- High Fire Resistance: Class A1 non-combustible material with excellent fire safety characteristics (FSI=0, SDI=5).
- Moisture Resistant: Hydrophobic treatment available upon request to prevent water absorption.
- Lightweight & Flexible: Easy to handle, cut, and install in various applications.
- Environmentally Friendly: Made from recycled glass content and free from harmful substances.
- Dimensional Stability: Low shrinkage rate (<2%) ensures long-term performance.
- Wide Temperature Range: Suitable for continuous use up to 600°C.
Available Specifications:
- Density: 50, 64, 80, 96, 120, 130 kg/m³ (customizable)
- Thickness: 50mm, 75mm, 100mm, 150mm (other thicknesses available)
- Standard Size: 1200mm × 600mm (custom sizes and rolls available)
- Facing Options: Plain, foil-faced, glass cloth, or other facings as required




Applications:
- Building Insulation: External walls, internal partitions, roofs, ceilings, and floors.
- HVAC Systems: Duct insulation, air handling units, and ventilation systems.
- Industrial Equipment: Boilers, furnaces, pipelines, and thermal equipment insulation.
- Acoustic Control: Sound absorption in studios, theaters, offices, and industrial noise reduction.
- Fire Protection: Fire barriers, fire-rated walls, and structural fireproofing.
- Commercial & Residential: Hotels, hospitals, schools, shopping malls, and residential buildings.
