Automated Double Glazing Machinery , Hollow Glass Making Machine CE Certification
Automated Double Glazing Machinery , Hollow Glass Making Machine CE Certification
Specifications
Brand Name :
LIJIANG
Model Number :
LJBZ2535
Certification :
CE
Place of Origin :
JINAN
MOQ :
1 SET
Price :
Negotiable
Supply Ability :
1set 30days
Delivery Time :
30days
Packaging Details :
40gp
Max glass size :
2500*4500mm
Min glass size :
300*500mm
Glass thickness :
3-15mm
Insulating glass thickness :
50mm
Glass washing speed :
2-10m/min
Glass conveyor speed :
48m/min
Washing brushes :
3 pairs
Oversea service :
available
Guarantee period :
12 MONTHS
Stepped glass :
available
Triple glass :
available
Shaped Glass :
availabe
Low-e glass :
available
Description

Automated Double Glazing Machinery , Glass Making Machine CE Certification

Automatic insulating glass production line, double glazed glass production line make double glass, triple glass, stepped glass and shaped glass.

Model Min size of glass(Optional) Max size of glass Low-E Stepped glass Triple glass Gas filling online
LJBZ1825 300*500 1800*2500 Available Available Available Available
LJBZ2025 300*500 2000*2500 Available Available Available Available
LJBZ2230 300*500 2200*3000 Available Available Available Available

LJBZ2535

(Optional)

 300*500 2500*3500 Available Available Available Available

Max.glass size 2500*3500mm/2200*3000mm/2000*2500mm
Min.glass size 280*450mm
Glass thickness 3-15mm
Insulating glass thickness 60mm
Glass washing speed 2-10m/min
Glass conveyor speed 48m/min
Washing brushes 3 pairs
Water supply Water consumption:0.5t/h conductivity:≤50μs/cm
Air supply Flow: 0.8m/min
Air pressure ≥0.8MPa
Total power 3P 380V 50HZ 40KW/27KW/24KW
