Stable Accurate Coriolis Flow Meter Mass Flowmeter Gas Slurry Media 3mm

Specifications

2.Accuracyclass :

Class 0.1\Class 0.15\Class 0.2\Class 0.5

5.Protection grade :

IP67

4.Signaloutput :

(4-20 mA of a current loop; 0-10 kHz of frequency, Modbus RS485, HART, FF)

6.Anti-hazard classification :

Exd Ⅱ BT3~6，Exd Ⅱ CT3~6.

Brand Name :

CQCY

Model Number :

Mass flowmeter

Certification :

CCS/ 3A/ TUV-SII2/3 /IEC Ex /ATEX /CE /NEPSI

Place of Origin :

Shanghai, China

MOQ :

1set

Price :

USD+50 dollars to 1000 dollars+1set

Payment Terms :

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability :

5000+1set+per day

Delivery Time :

10-30 work days

Packaging Details :

Carton packing

3.Medium temperature :

-70-120°CCryogenic type:-200-60°C: High temperature type: -40-300°C)

1. Calibration range. :

DN3mm-DN300mm

Description

Mass flowmeter (Fluid mass and density were measured/Liquid, gas and slurry media for stable and accurate measurement

' mass flowmeter' functions based on the Coriolis principle. Themedium vibrates when it flows through the flow tube. The sensormeasures the mass flow rate and density of the fluid by detectingand analyzing changes in the frequency, phase difference, andamplitude of the measuring tube. The mass flowmeter is equippedwith a precision temperature measurement sensor inside, which hasexcellent flow and density measurement performance and canmeasure liquid, gas, and seriflux media stably and accurately.

Product features:

1.Multiple parameters, including mass flow rate, volume flow rate, density, and temperature are allowed to be measured accurately.

2.Double U-shaped measuring tube, with high sensitivity.

3.The measurement is not affected by changes in fluid density, viscosity, and temperature.

4.The product is not affected by installation and environment and can maintain long-term stability.

5.The installation is simple, and straight pipe sections and rectification are not required.
