Specifications
Place of Origin :
Shenzhen,China
Brand Name :
Inrover
Model Number :
MQR
Packaging Details :
Plastic tubes+ Carton Box
Supply Ability :
30000pcs/month
Price :
Please Contact Supplier
MOQ :
5
Payment Terms :
T/T
Delivery Time :
5-15 days
Warranty :
3 years
Customized support :
OEM, ODM, OBM
Usage :
Internal Turning Tool
Hardness :
HRC 91-93.5
Coating :
To be defined, With or without coat, Nano coating
Type :
Internal hole profiling boring tool
Material :
Tungsen Carbide
Precision :
±0.005mm
Flute length :
10mm-30mm
Tip arc :
R0.10-R0.15
Penetration depth :
0.60mm-1.20mm
Shank diameter :
4mm-6mm
Controlling Mode :
Lathe Insert
Machining type :
boring tool
Shank Type :
Round shank
Port :
shenzhen
Certification :
ISO9001
Description

High Efficient Carbide Cutters Profiling Boring Tools For Mini CNC Lathe Machine Accept OEM Internal Coolant Custom Tool

Specification

Profiling Micro Boring Tool Tungsen Carbide Material For Mini CNC Lathe Machine

Profiling Micro Boring Tool Tungsen Carbide Material For Mini CNC Lathe Machine

Technical Parameters

Profiling Micro Boring Tool Tungsen Carbide Material For Mini CNC Lathe Machine

Type Inner hole Profiling boring tool
Product name MQR tungsten carbide Inner hole Profiling boring tool
Brand Name INROVER
Material Tungsten Carbide
Precision ±0.005mm
Coating Nano coating
Weight of item(WT) 0.02kg
Machining type Profiling and Boring Tool
Product color gold
cutting depth 0.05-0.5mm
Feed rate 0.03-0.1mm/r
Linear velocity Vc 20-100m/min
Suitable for machine tools CNC lathes, centering machines, cutter arranging machine skateboard lathes,turret lathes and other longitudinal lathes
Mainly suitable for machine tool brands Swiss TORNOS lathe, Citizen, Nomura, Tsugami,Star,Miyano,etc
Product Features 1. Smooth chip evacuation and efficient machining
2. The boring tool is integrally formed
3. Imported machine tool precision grinding
4. Nano coating is wear-resistant and durable
5. Round shank design, tightly bonded, with internal coolant of INSIGHT tool sleeve, improve efficiency and service life, reduce
Rigorous quality inspection 1.Projector detection
2.ZOLLER detection
3.Swis edging
4.German forging difference process detection
5.Edge passivation detection
6.Coreless grinding
