HJF180 plastic Injection Molding Machine 180 Tons with T slot platen
HJF180 plastic Injection Molding Machine 180 Tons with T slot platen
HJF180 plastic Injection Molding Machine 180 Tons with T slot platen
HJF180 plastic Injection Molding Machine 180 Tons with T slot platen
Specifications
Brand Name :
Haijiang
Model Number :
HJF180
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
500sets/month
Delivery Time :
25 days
Packaging Details :
Export Standard
product name :
Auto Injection Molding Machine
clamp Tonnage :
1800
Toggle stroke :
430
space between tie bars :
470*470
Machine Dimension :
5.1*1.4*1.9
pump motor power :
15KW
Description

HJF180 plastic Injection Molding Machine 180 Tons with T slot platen

Main technical parameters

SPECIFICATION HJF-180
A B C
Screw diameter mm 42 45 50
Screw L/D Ration L/D 22.5 20 18.8
Shot size(theoretical) cm³ 304 349 431
Injection weight(PS) g 274 314 388
Injection rate g/s 108 128 158
Injection pressure Mpa 202 159 140
Screw speed rpm 0-185
Clamping tonnage KN 1800
Opening stroke mm 430
Space between the tie bars mm 470*470
Max.mold height mm 500
Min.mold height mm 180
Ejector stroke mm 130
Ejector tonnage KN 45
Max.pump pressure Mpa 16
Pump motor power KW 15
Heater power KW 7.5
Machine dimension(L*W*H) M 5.1*1.4*1.9
Machine weight T 5.5
Oil tank capacity L 240

Quick Detail:

Industrial Plastic Injection Molding Machine is for normal type plastic material injection, e.g. PC, PP, PE, Nylon, A.B.S.etc.This machine is mainly used to produce middle&big industrial parts, household appliances and other plastic products.

Competitive advantages:

+injection Units

High injection pressure , High injection speed

+HYDRAULIC SYSTEM

Fast respone, stable output

+Electronic Units

intelligent control unit

Characteristics

1. Adopts the imported control components, durable, safe, and low failure rate.

2. Use human-computer interface, simple and more visually oriented.

3. The machine uses machine electrical and air linkage, excellent effect of bottom sealing.

4. East to adjust different sizes of cartons, adjust quickly and easily, available for a wide range of cartons.

5. Low power consumption, simple and convenient operation, low noise.

6. Use tap to seal the cartoon bottom, protected from weather, sealing reliable.

Shipping and Payment

Product Name 500 Injection molding machine
Packing Export standard package
MOQ 1 set
FOB price Please contact for new price
Delivery time 60days
FOB port Ningbo
Payment terms T/T,L/C at sight
