Medical-Grade Implantable Electrode Silicone Insulation Sleeve Molding Machine
Medical-Grade Implantable Electrode Silicone Insulation Sleeve Molding Machine
Medical-Grade Implantable Electrode Silicone Insulation Sleeve Molding Machine
Medical-Grade Implantable Electrode Silicone Insulation Sleeve Molding Machine
Specifications
Brand Name :
Better
Model Number :
Better 200
Certification :
CE、ISO
Place of Origin :
GuangZhou，China
MOQ :
1 SET
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
15 sets per month
Delivery Time :
40 days
Packaging Details :
Plastic film
Core Components :
Motor, PLC, Engine, Screw
Machinery Test Report :
Provided
Components :
Techmation, Schneider，AirTac
Economic Benefits :
Obvious--30-50% electricity can be saved
Description
Medical-Grade Implantable Electrode Silicone Insulation Sleeve Molding Machine
Technical Specifications
Machine Model BETTER Vertical Rotary LSR Injection Molding Machine
Clamping Force 85 tons
Size Φ1180
Maximum Mold Size 430 × 430 mm (600 × 350 mm)
Minimum Mold Height 210 + 50 mm
Mold Stroke 250 mm
Maximum Daylight 460 + 50 mm
Ejector Force 3 tons
Thimble Diameter Φ25
Ejector Distance (Product) 105 (75) mm
Maximum Hydraulic Pressure 140 kg/cm²
Cooling Water 1500-1800 liters/hour
Electrothermal 4 kW
Motor 13 kW
Dimensions (L × W × H) 2.84 × 2.13 × 2.86 / 3.67 m
Weight 5.5 tons
Complete Turnkey Solutions
A stable and cost-effective production process depends significantly on component quality and proper coordination between individual elements. As a full system supplier, BETTER develops and manufactures all essential components for LIM production cells in China, adhering to stringent quality standards.
With extensive experience, BETTER specializes in integrating its product range with appropriate injection molding machines and automation components into complete production cells. Customers specify part geometry, tolerances, production volumes, and additional requirements, and BETTER delivers fixed-price turnkey solutions including all necessary components, comprehensive acceptance procedures, and required training.
LSR Injection Molding Industry Applications
Maternal and Baby Industry:
  • Non-polluting safety and forming process of liquid silicone materials
  • Widely used for nipples, pacifiers, teethers, bottles, spoons, suckers, brushes, and other silicone products
Medical Industry:
  • Excellent biological characteristics and high-quality forming technology
  • Applications include catheters, joints, gastric tubes, laryngeal masks, masks, dental brackets, negative pressure balls, incision protective covers, and balloons
Electronics Industry:
  • Waterproof, elastic, and high-precision forming capabilities
  • Used for joint waterproof seals, horn diaphragms, mobile phone cases, watch bands, buttons, and earphones
Automotive Parts Industry:
  • High permeability and efficient production processes
  • Applications include LED perspective mirrors, spark plug protectors, wire harness seals, and sealing strips
