Specifications
Brand Name :
Better
Model Number :
Better 1600SD-3RT
Certification :
CE、ISO
Place of Origin :
GuangZhou,China
MOQ :
1 SET
Price :
USD42000-USD82000per set
Payment Terms :
T/T,D/P,D/A,L/C
Supply Ability :
20 sets per month
Delivery Time :
45 days
Packaging Details :
Plastic film
Clamping Stroke :
Variable
Machine Weight :
9.6T
Machine Type :
Hydraulic, Other
Power Source :
Electric/Hydraulic
Transport :
by sea
Type :
Vertical
Automatic :
Yes
Description

Liquid Silicone Injection Molding Machine for Apple Phone Case Production

Specifications:

BETTER Vertical LSR injection molding machine
clamping force 160tons
size 1500*730mm
max mold size 720*660mm
Min mold height 300+50mm
mold stroke 300mm
max daylight 600+50mm
ejector force 4tons
Thimble diameter Φ25
ejector distance(product) 130(100)mm
Max hydraulic pressure 140kg/cm2
cooling water 1500-1800liters/hr
Heater Power 4kw
Motor Power 22kw
Dimension (L*W*H) 2.86*2.76*3.30
weight 9.6tons


Service

The professional service from better

Pre -sale service:

Provide investment budget and plant planning,Provide a whole set of solutions about machine and mold according to products that customers offered.

On-sales service:

Provide installation and new machine debugging services for users who purchase better machine* Free tranning for your staff who can operate and maintain the machine independently in your factory.

After-sales service:

Timely dispatch personnel to the user's site to solve after-sales problems and solve difficult technical problems;

After product upgrading, the upgrading work of previous users shall be given priority as required;


When is Liquid Silicone Rubber the Best Choice?

One of the primary advantage of liquid silicone rubber elastomers. LSR materials are offered in a wide variety of grades: general purpose, food-grades, medical, self-adhesive, low-volatile, optically clear and numerous other specialty grades, each in a range of durometers – from very firm to very soft. Liquid silicone rubber elastomers are also inherently insulating, offering superior heat and flame resistance ideal for electrical, automotive, and industrial applications. LSRs are also naturally biocompatible and hypo-allergenic making them a choice material for skin-contact products. LSR’s physical properties are also a key factor contributing to their popularity. Due to its high compression set, an LSR part will maintain its original shape after numerous compressions/uses, even in extreme high and low temperatures – a differentiating factor between liquid silicone rubber and other elastomeric polymers. These highly versatile silicone materials are naturally translucent white in color however they can be pigmented in a variety of colors.

Just about every industry imaginable has discovered the opportunities that LSR and the liquid injection molding process offers for their products, including:

1,Seals, gaskets and thin membranes;

2,Insulators and cushions;

3,Valves and bladders;

4,Respiratory masks;

5,Syringes and IV components;

6,Wearable health monitoring devices;

7,Electronic components ;

8,Food and beverage products;

What Makes Silicone Rubber So Desirable?

Silicone rubber is a synthetic elastomer made from silicon, oxygen, hydrogen, and carbon. Known for its exceptional resistance to extreme temperatures, ranging from -60°F to 450°F[KC1], silicone rubber is highly durable and flexible. It also possesses strong resistance to environmental elements like UV light, moisture, and ozone, making it suitable for outdoor and demanding applications.

These properties make silicone rubber the go-to material for industries that require long-lasting, high-performance solutions. Its ability to maintain stability in harsh conditions allows manufacturers to rely on it in critical applications.

Below, we will review the wide range of silicone rubber applications across industries such as automotive, energy, aerospace, and more, demonstrating its integral role in modern technology and infrastructure.
