24 Pins Rectangle Male Connector Injection Molding Services , Electronic Injection Molding
24 Pins Rectangle Male Connector Injection Molding Services , Electronic Injection Molding
24 Pins Rectangle Male Connector Injection Molding Services , Electronic Injection Molding
24 Pins Rectangle Male Connector Injection Molding Services , Electronic Injection Molding
Specifications
Brand Name :
Own
Model Number :
CI-007
Certification :
ISO90001
Place of Origin :
China
MOQ :
MOQ 500 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
100000 Sets per month
Delivery Time :
45-50days
Packaging Details :
Polybag and Master carton
Base :
KLM tooling base
Mold life :
300,000-500,000 shots
Cavity :
Single cavity
Feeding :
Injection molding
Cavity& Core material :
ASSAB P20, 718, S136, H13, 8407, NAK80 and more
Pole :
3, 4, 5 Poles
Description
24 Pins Rectangle Male Connector Injection Molding Services
Rectangle Male Connector / IP67 / Electronics Injection Moulding / Screw Connection / 24 Pins
Electronics Injection Molding Applications
Electronic components for Automatic industries, IP67. We have very clean injection work shop and assembly line, providing not only injection molding service but full product development service.
Rectangle Connector Electronics Specifications
Current 10A Max
Voltage 250 V
Testing Voltage 4KV
With UL 94V0 Flame Retardant Level, and IP65 protective level. The Pin material is Copper with Silver plated or Golden plated. The connectors resistance achieves less than 3mΩ, working temperature range from -40°C to +125°C.
We not only manufacture electronic connectors, but also provide various electronic solutions such as Thermal silicone pad die cutting material, adhesive tape material die cutting service, etc.
Our Clean Assembly Line
24 Pins Rectangle Male Connector Injection Molding Services , Electronic Injection Molding
Tooling and Production Services
We design and manufacture tooling for clients and produce customized injection parts. We export high-quality tooling at competitive prices and specialize in OEM product development and production.
Design and Production Flow
STEP Process
1 Receive client's 2D and 3D drawing (preferably in .step format)
2 DFM analysis on the 3D drawing, Part line, core and cavity design
3 Communication with clients regarding DFM analysis
4 Tooling design and tooling plan
5 Tooling manufacturing (CNC machining, EDM process, tooling assembly)
6 First trial on the tooling, Tooling analysis after first trial, OTS checking
7 Tooling etching or final polishing after first samples approval
8 Golden samples trial and samples approval
9 Pilot production and mass production
Competitive Advantage
  • 13 Years OEM and ODM experience in plastic injection molding service. One stop tooling room and clean injection workshop.
  • All injection machines with controlled system robot.
  • Advanced equipment and professional technology: CNC, 2D, 2.5D and injection machines.
  • Advanced R&D service and Best Engineer: DFM and Mold Flow Analysis.
  • Excellent Dual shot injection molding technology.
  • Quality and Price: Quality-oriented and cost drivers analysis to share cost reduction with customers.
  • Series service of design, prototyping, painting, printing and assembly (several assembly lines and one clean assembly room for finished products).
Frequently Asked Questions
Q1. Can I order the connector if the quantity is very small?
Yes, we accept small orders.
Q2. How can I place an order?
Please contact any of our sales persons for an order, and provide the details of your requirements as clear as possible.
Q3. How can I get a sample to check your quality?
After price confirmation, you can request samples to check our quality and need to afford the express freight.
Q4. Can you do the design for us?
Yes. We have a professional team with rich experience in plastic products design and manufacturing. Just let us know your ideas and we will help carry out your ideas into perfect products.
Q5. How long can I expect to get the sample and mass production?
For existing mold: samples ready in 3-7 days, mass production in 1-2 weeks. For new mold: 25-35 days for mold building, mass production in 1-4 weeks.
Q6. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the most convenient or cost effective option for you.
