Specifications
Brand Name :
jasu
Model Number :
ISB 800-3
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
10000usd
Payment Terms :
D/P,T/T,Western Union
Supply Ability :
100unit/month
Delivery Time :
7-10days
Packaging Details :
wooden box
voltage :
380V 50HZ
application :
Bottle
plastic processed :
PE, PET
blow moulding type :
Injection Blow Moulding
core components :
PLC, Motor
dimension(l*w*h) :
3.8X1.5X3.2M
automation :
Automatic
Description

Used Jasu PE PET Automatic One-step Injection Blow Molding Machine for sale

Used Jasu Automatic PE PET One-step Injection Blow Molding Machine for Bottle Production

Used Jasu Automatic PE PET One-step Injection Blow Molding Machine for Bottle Production

Used Jasu Automatic PE PET One-step Injection Blow Molding Machine for Bottle Production

Model

 ISB 800-3
Injection Part
Screw Diameter 40mm
Screw L/D Ratio 20.5:1
Screw Speed 0-190RPM
Theoretical Injection Capacity 238cm3
Injection Pressure 174Mpa
Max. Hydraulic Pressure 140Kg/cm
The Actual Injection Quantity(PS): 225g(ps)/8Oz
Screw Stroke: 190Mm
Clamping Part
Blow Clamping Force: 80Kn
Clamp Tonnage: 400Kn
Wheel Diameter: 800mm
Max. Height of Bottle: ISB:145/IB:140
Open Vertical Mode Trip: 430mm
Others
Max. Pump Pressure: 16Mpa
Motor Oil: 18.5Kw
Electric Power: 12.2Kw
Oil Tank: 400L
Overall Dimension(L*W*H): 3.8m*1.45m*3.0m
Weight: 5000kg


Compare with One-step and Two-step:

Molding Process Structure Manpower/Energy/Space Product Quality
One-step From preform to product One machine Little Not affect by damp and less pollution; Various kinds of shape
Two-step Injection and blow molding are two separated process

1.Injection molding machine

2.Preform transiting machine

3.Reheating, stretch and off-moulding machine

 More Easy affect by damp and polluted; Singleness shape
