E H Instrument 5W4C2F AAILHP3AUA1KGB AACQEB Electromagnetic Flowmeter Designed for Industrial Liquid Flow Monitoring
E H Instrument 5W4C2F AAILHP3AUA1KGB AACQEB Electromagnetic Flowmeter Designed for Industrial Liquid Flow Monitoring
E H Instrument 5W4C2F AAILHP3AUA1KGB AACQEB Electromagnetic Flowmeter Designed for Industrial Liquid Flow Monitoring
E H Instrument 5W4C2F AAILHP3AUA1KGB AACQEB Electromagnetic Flowmeter Designed for Industrial Liquid Flow Monitoring
Specifications
Brand Name :
Endress Hauser
Model Number :
5W4C2F-AAILHP3AUA1KGB+AACQEB
Certification :
CE
Place of Origin :
Germany
MOQ :
1pcs
Price :
USD4833/PCS
Payment Terms :
T/T
Delivery Time :
5-8works
Packaging Details :
carton
Warranty :
1 Year
Name :
5W4C2F
Output Signal :
4-20 MA, HART, Modbus
Measurement Type :
Flow
Degree Of Protection :
IP66/67, Type 4X Enclosure
Highlight :
German E+H Electromagnetic Flowmeter, AACQEB German E+H Flowmeter, 5W4C2F-AAILHP3AUA1KGB
Description
E+H Instrument 5W4C2F AAILHP3AUA1KGB AACQEB Multifunctional Electromagnetic Flowmeter
German-engineered multifunctional standard electromagnetic flowmeter designed for industrial flow monitoring in water and wastewater applications.
Product Overview
The Promag W 5W4C2F-AAILHP3AUA1KGB+AACQEB is a multifunctional standard flow meter specifically designed for the water and wastewater industry. With dosing transfer and drinking water certification, it offers versatile application capabilities in both one-piece and split versions.
Key Advantages
  • High-precision, reliable measurement without requiring front and rear straight pipe sections
  • No pressure loss during operation
  • Flexible installation with fully welded or loose flange process connections
  • EN ISO 12944 corrosion protection for direct underground or underwater use
  • Industry-specific sensor configurations
  • Safe operation with backlit display and touch control
  • Integrated web server for localized operations
  • Heartbeat Technology with integrated checksum for reliability
Application Fields
Expert in drinking water, utility water, and industrial/municipal wastewater measurements. The bidirectional measuring principle eliminates the need to account for pressure, density, temperature, and viscosity conditions.
Certifications & Standards: Drinking water certification, IP68 protection (6P housing), complies with MI-001/OIML R49 standard with measurement transfer certification.
Technical Specifications
Nominal Caliber Range DN 25...2000 (1...78")
Wetted Parts Material Lining: Polyurethane, Ebonite
Electrodes: 1.4435 (316L), Alloy C22 2.4602 (UNS N06022), Tantalum
Measure Variables Volumetric flow, Conductivity, Mass flow
Measurement Accuracy Volume Flow Rate (typical): ±0.5% o.r. ± 1 mm/s (0.04 in/s)
Sensor Features
  • Robust one-piece welded sensors for safe, reliable long-term operation
  • Energy-saving flow measurement with no additional devices in pipeline
  • Maintenance-free design with no moving parts
  • Drinking water certified with IP68 (Type 6P) protection
Transmitter Features
  • Backlit display with touch key control - no need to open instrument
  • Built-in web server for time-saving on-site operations
  • Heartbeat Technology for self-check capabilities
  • Durable polycarbonate or aluminum housing options
  • WLAN access capability
