Bently Nevada Dual Probe Transducer System with 3300 XL 8 mm Probes and CE ATEX Certification
Bently Nevada Dual Probe Transducer System with 3300 XL 8 mm Probes and CE ATEX Certification
Bently Nevada Dual Probe Transducer System with 3300 XL 8 mm Probes and CE ATEX Certification
Bently Nevada Dual Probe Transducer System with 3300 XL 8 mm Probes and CE ATEX Certification
Specifications
Model Number :
26530-05-10-00-000-088-14-04-00
Payment Terms :
T/T
Price :
1990
Delivery Time :
4-6 weeks
Certification :
CE ATEX
MOQ :
1
Brand Name :
BENTLY NEVADA
Place of Origin :
USA
Description
26530-05-10-00-000-088-14-04-00 Bently Nevada Dual Probe Transducer System
Product Overview
The 26530 Dual Probe Transducer System combines proximity and seismic/Velomitor® transducers in a common housing for comprehensive machinery monitoring and vibration analysis.
Technical Specifications
Place of Origin USA
Brand Name BENTLY NEVADA
Certification CE ATEX
Model Number 26530-05-10-00-000-088-14-04-00
Key Features
Bently Nevada dual probe transducer
GE Bently Nevada transducer system
Dual probe transducer with warranty
System Description
The Dual Probe Transducer System consists of a proximity probe and a seismic or Velomitor® transducer installed at approximately the same point in a common transducer housing. This transducer system is capable of making four separate measurements:
  • Shaft relative radial position (displacement) relative to the probe mounting location, measured by the proximity probe
  • Shaft relative radial dynamic motion (vibration) relative to the probe mounting location, measured by the proximity probe
  • Machine casing absolute vibration measured by the seismic vibration
  • Shaft absolute motion represented by the summation of the seismic signal (after integration to displacement) and the shaft relative displacement
The Dual Probe Transducer System provides the best measurement data when the transducer housing is mounted on a portion of the bearing housing or cover that is mechanically referenced to the bearing.
Temperature Range
3300 XL 8 mm Probe: -51°C to +177°C (-60°F to +351°F)
Note: Exposing the 3300 XL probe to temperatures below -34°C (-30°F) may cause premature failure of the probe pressure seal.
Compatible Spare Probes
330105-02-12-CXX-DXX-EXX: Spare 3300 XL 8 mm Reverse Mount Probe, 3/8-24 UNF threads
330106-05-30-CXX-DXX-EXX: Spare 3300 XL 8 mm Reverse Mount Probe, M10 X 1 threads
