Electric Industrial Air Compressor 30hp 22kw Customized
Electric Industrial Air Compressor 30hp 22kw Customized
Electric Industrial Air Compressor 30hp 22kw Customized
Electric Industrial Air Compressor 30hp 22kw Customized
Electric Industrial Air Compressor 30hp 22kw Customized
Electric Industrial Air Compressor 30hp 22kw Customized
Electric Industrial Air Compressor 30hp 22kw Customized
Electric Industrial Air Compressor 30hp 22kw Customized
Specifications
Brand Name :
Shanhai
Model Number :
KRW1.7/30D
Certification :
ISO9001
Place of Origin :
zhejiang, China
MOQ :
1
Price :
US$1800-5000/pcs
Payment Terms :
T/T
Supply Ability :
100pcs per month
Delivery Time :
3-10 days after the payment
Packaging Details :
wooden box/air column packing
Working pressure :
3.0Mpa/ 30bar air compressor
Air delivery :
1.7m3/min
Voltage :
380v/3ph/50hz(or Customized)
Condition :
New
Mute :
No
Power source :
AC Power
Type :
Piston,Reciprocating,Stationary
Cooling method :
Air Cooling
Configuration :
Stationary
Lubrication style :
Oil-less
Description

Stationary 30bar 40 bar 50bar Compressors Electric 30hp 22kw Piston Type Industrial Air Compressor

Application

This seires air compressor widely used in pneumatuic lock, pneumatic tool, tire inflation,blowing process,spray, paint,sand bklsting and fluidic element.

Advantages


>Maximum space saving through compact design. All Nascent componentsare mounted on a common base frame to ensure premium space saving.

>Smooth operation for maximum machine life.Considerable time and engineering goes into the design of the generously dimensioned shock
absorbers and rigid base frame in order to guaranteed minimal vibration.

>Ease of maintenance, best access and user friendliness are all integral to the machine design. Simple operation,simple maintenance and easy adaptation to special requirements saves time and saves money.

MODEL
F.A.D.
PRESSURE
MTR POWER
MTR SPEED
OIL CONTENT
WEIGHT
DIMENSION
m^3/min
BAR
HP/KW
RMP
L
KG
L*W*H (mm)
KRW0.63/30D
0.63
30
10/7.5
600
6
400
1400*710*850
KRW1.0/30D
1.0
30
15/11
660
6
420
1400*710*850
KRW1.2/30D
1.2
30
20/15
800
6
420
1420*710*885
KRW1.35/30D
1.35
30
20/15
800
6
420
1420*710*885
KRW1.6/30D
1.6
30
25/18.5
720
10
610
1460*770*1040
KRW1.7/30D
1.7
30
30/22
750
10
620
1460*770*1040
KRW2.0/30D
2.0
30
30/22
750
10
620
1530*830*1100

Electric Industrial Air Compressor 30hp 22kw CustomizedElectric Industrial Air Compressor 30hp 22kw CustomizedElectric Industrial Air Compressor 30hp 22kw Customized

packing&delivery as following:

Electric Industrial Air Compressor 30hp 22kw Customized

after -sale as following:

​Electric Industrial Air Compressor 30hp 22kw Customized

ATTENTION:

We can change the electric power to 60HZ,220v etc power,we have exported a lot worldwide with matched air dryer,air tank.
