2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
2.4m3/min 350L Piston Air Compressor For PET Blowing Machine
Specifications
Brand Name :
Kaishan
Model Number :
2*KB-15
Certification :
ISO9001
Place of Origin :
Quzhou China
MOQ :
1
Price :
US$5600-7000/pcs
Payment Terms :
T/T
Supply Ability :
100pcs per month
Delivery Time :
3-10 days after the payment
Packaging Details :
wooden box/air column packing
Working pressure :
3.0Mpa/ 30bar
Air delivery :
2.4m3/min
Voltage :
380v/3ph/50hz(or Customized)
Condition :
New
Power source :
AC Power
Type :
Piston,Reciprocating,Stationary
Cooling method :
Air Cooling
Product name :
20hp portable industrial air compressor for sale
Description

Popular Kaishan 30Bar 350L Piston Air Compressor KB-15 For PET Blowing Machine

Introduction of 2*KB-15 air compressor

This series is professional designed by computer with higher stability and reliability. Its low-speed design makes the products have low-noise running and long lifespan. It has the excellent air supply ability and good sealing performance.

Characteistics

a. Strongly power driven and big air end with design, the air compressor owns bigger and heavier main parts than other products in the same trade with better selection and sufficient using of materials especially with main fittings, In addition ,it is more suitable to be applied in the continuous operation under heavy load for long working time

with higher reliability and longer lifespan

b. Special designed is made in heat emission and air flow, which leads to low air-output temperature and low possibility of carbon deposit

c. Composite ring valve is adopted in design, with the vavle plate made of stainless steel from Swden and the spring of vavle block made of special sping steel wire from Japan withno bending motion in operation, the vavle compresses excellent property and ideal lifespan index.

d. The piston ring imported from Japan is introduce in designing pistol ring , which is durable and sealable .

2.4m3/min 350L Piston Air Compressor For PET Blowing Machine

Model

 Motor Power (HP/KW) Capacity (m3/min) Working Pressure (Mpa) Dimensional Size (mm*mm*mm) Weight (kg)
4*KB-15G 4*20/15 4.8 3.0 1870*1770*1487 2100
2*KB15G 2*20/15 2.4 3.0 1616*1030*1452 1000

2.4m3/min 350L Piston Air Compressor For PET Blowing Machine

Model

 Motor power HP/KW air delivery M3/min Working pressure Mpa

Air tank

m3

 Dimension mm

Weight

kg
KB-10

15/11

0.7

3.0

 0.25 1690×690×1190 550
KB-10 No air tank 1550*660*915 440
KB-15

20/15

1.2

3.0

 0.34 1810×710×1310 600
KB-15 No air tank 1380*662*910 480
KBL-15 20/15 1.3 2.5 0.34 1810×710×1310 600

other products introduction are as following:

2.4m3/min 350L Piston Air Compressor For PET Blowing Machine

packing&delivery as following:

2.4m3/min 350L Piston Air Compressor For PET Blowing Machine

after -sale as following:

​2.4m3/min 350L Piston Air Compressor For PET Blowing Machine

ATTENTION:

We can change the electric power to 60HZ,220v etc power,we have exported a lot worldwide with matched air dryer,air tank.
