Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor
Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor
Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor
Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor
Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor
Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor
Specifications
Brand Name :
Luma
Place of Origin :
Zhongshan Guandong province China
MOQ :
4
Price :
/
Payment Terms :
L/C,wechat,alipay
Supply Ability :
100000
Delivery Time :
5-10days
Packaging Details :
bags and cartons
Inches :
4-8 inches
Braketype :
Brakin / brake/ Swivel/ Fixed
Productname :
Industrial Wheel Casters
Color :
Black / Grey / Blue
Usage :
Industrial Manufacturing/ Warehousing and Logistics /Medical and Healthcare/ Commercial and Retail/ Office and Institutional Settings/ Home and Furniture
Material :
PU
Finish :
Zinc Plated
Bearingtype :
Ball Bearing
Wheeltype :
Braking Side brake Swivel Fixed
Mountingtype :
Top Plate
Sample :
1pcs ，price add 50%
Description
Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8inches For Hard Surfaces Concrete Floor
Applications

Application Scenarios

  • Industrial Use: Due to its robust design and large diameter, this wheel is very suitable for industrial environments, such as moving heavy equipment within factory workshops.

    Commercial Use: In commercial environments, such as warehouses or retail stores, this wheel can be used to move shelves or other large items.

    Home Use: Although not specifically designed for this, it can also find use at home, such as for moving furniture or gardening tools.

Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor

Sizes
Common sizes include 4 inches, 5 inches, 6 inches, and 8 inches.

the 8-inch caster is suitable for heavier loads, such as large industrial trolleys or vehicles.

Product Specifications
Product Name Specification Wheel Diameter (mm) Wheel Width (mm) Installation Height (mm) Bracket Thickness (mm) Base Plate Size (mm) Hole Distance (mm) Hole Diameter (mm) Load Capacity (kg) Wheel Material
4-inch Fixed Direction 100-4" 50 150 5.5 115 * 100 82 * 72 13 350 PU
4-inch Omnidirectional 100-4" 50 150 5.5 115 * 100 82 * 72 13 350 PU
4-inch Brake 100-4" 50 150 5.5 115 * 100 82 * 72 13 350 PU
5-inch Fixed Direction 125-5" 50 169 5.5 115 * 100 82 * 72 13 400 PU
5-inch Omnidirectional 125-5" 50 169 5.5 115 * 100 82 * 72 13 400 PU
5-inch Brake 125-5" 50 169 5.5 115 * 100 82 * 72 13 400 PU
6-inch Fixed Direction 150-6" 50 190 5.5 115 * 100 82 * 72 13 450 PU
6-inch Omnidirectional 150-6" 50 190 5.5 115 * 100 82 * 72 13 450 PU
6-inch Brake 150-6" 50 190 5.5 115 * 100 82 * 72 13 450 PU
8-inch Fixed Direction 200-8" 50 240 5.5 115 * 100 82 * 72 13 500 PU
8-inch Omnidirectional 200-8" 50 240 5.5 115 * 100 82 * 72 13 500 PU
8-inch Brake 200-8" 50 240 5.5 115 * 100 82 * 72 13 500 PU
Matching Specifications
  • Set 1: 2*brakes + 2* fixed
  • Set 2: 2*swivel + 2* fixed

Easy Installation: There is a square mounting plate on top of the wheel with four holes, making it easy to fix onto various equipment and increasing usage flexibility.

Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor

Features and Differences
  • Large Diameter Design: The wheel features a large diameter, which helps reduce pressure on the ground during movement, thereby lowering the risk of wear and allowing it to roll over obstacles more smoothly.
  • Small Contact Area: Despite the large diameter, the wheel’s contact area is relatively small. This means it is likely better suited for hard surfaces like concrete or tiles rather than soft ground, as the latter could cause the wheel to sink in.
  • Sturdy and Durable: Visually, the wheel appears to be made of robust materials, possibly metal or high-strength plastic, indicating it can withstand heavy loads without easy damage.
  • Easy Installation: There is a square mounting plate on top of the wheel with four holes, making it easy to fix onto various equipment and increasing usage flexibility.

Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor Robust Design And Large Diameter PU Extra Heavy Duty Caster 4-8 Inches For Hard Surfaces Concrete Floor
