Classifier Rubber Granule Professional 11.52m2 Vibrating Sieve
Classifier Rubber Granule Professional 11.52m2 Vibrating Sieve
Classifier Rubber Granule Professional 11.52m2 Vibrating Sieve
Classifier Rubber Granule Professional 11.52m2 Vibrating Sieve
Specifications
Brand Name :
TECHANG
Model Number :
TCXZS
Certification :
Food Processing
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 sets/month
Delivery Time :
20 working days
Packaging Details :
Wooden case
Name :
Classifier Manufacturer Rubber Granule Professional Vibration Screen Sieve
Input size :
≤10 mm
Dimension(l*w*h) :
Variable
Screening mesh area :
1.62~11.52m2
Customized :
Acceptable
Layer :
1-5
Mesh size :
0-500 mesh
Description

Classifier Manufacturer Rubber Granule Professional Vibration Screen Sieve

Introduction


Classifier Manufacturer Rubber Granule Professional Vibration Screen Sieve is a high precision fine powder sieving machine. The fundamental principle of round separator is that the eccentric hammers installed on the top and bottom ends of motor changes the rotation motion of motor to horizontal, vertical and inclined three-dimensional motions, and then passes this motion to screen surface, achieving the purpose of classification, filtering and removal of impurities.

Classifier Rubber Granule Professional 11.52m2 Vibrating Sieve

Advantages

1. Can be used with single or multilayer screen mesh.

2. Automatic discharge of materials, continuous operation.

3. No dead corner of parts, easy rinse thoroughly and disinfection.

4. High screening precision, high efficiency, suitable for any powder, grain and mucus materials.

5. New grid structure, long service life of screen cloth, only 3-5min for screen replacement.

6. Small volume, less space occupation, easy to move,360 degree adjustment of discharge opening.

7. Fully enclosed structure, no flying dust, no liquid leakage, no blocking of mesh opening, screen can reach 500 meshes, and filter can reach 5 um.

Structure

Classifier Rubber Granule Professional 11.52m2 Vibrating Sieve

Application


1. Chemical industry: resin, pigment, cosmetic, coatings, Chinese medicine powder.
2. Food industry: sugar powder, starch, salt, rice noodle, milk powder, egg powder, sauce.
3. Metallurgy, Mine industry: aluminum powered, copper powder, ore alloy powder, welding rod powder.
4. Medicinal industry: all kinds of medicine.
5. Waste treatment: disposed oil, disposed water, disposed dye waste water, active carbon.

Classifier Rubber Granule Professional 11.52m2 Vibrating Sieve

Technical data

Model

Power

(kw)

Diameter

(mm)

 Layer

Mesh Size

(mesh)

Frequency

(rpm)
TCXZS400 0.37 360 1-3 1-500 1500
TCXZS600 0.55 560 1-3 1-500 1500
TCXZS800 0.75 760 1-3 1-500 1500
TCXZS1000 1.1 960 1-3 1-500 1500
TCXZS1200 1.5 1130 1-3 1-500 1500
TCXZS1500 2.2 1430 1-3 1-500 1500
TCXZS1800 2.2 1730 1-3 1-500 1500
TCXZS2000 3 1730 1-3 1-500 1500
