22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
Specifications
Brand Name :
FLEXEM
Model Number :
FE5220
Certification :
CE
Place of Origin :
Shenzhen
Packaging Details :
Carton
MOQ :
1pc
Price :
Negotiation
Payment Terms :
T/T
Delivery Time :
1-7 business days after payment confirmed
Supply Ability :
5000 pcs/week
Display :
22“ TFT LCD
Resolution :
1920×1080
Colors :
16-bit color
Brightness :
250 cd/m²
CPU :
800MHz ARM Cortex A8
Memory :
256M Flash+256M DDR3
Description

Metal Capacitive HMI FE5220 22 inch TFT LCD full HD high resolution multi-touch capacitive touch panel


Description:

* ​Projected capacitive, multi-touch Glass+Glass touch screen.

* 22inch 1920*1080 IPS LCD, high brightness, high contrast ratio, full viewing angle.

* Aluminum panel, metal frame, exquisite and metallic appearance, with only 31mm thickness.

* Industrial isolation power supply, spray coating treatment and applicable to various harsh environment.

* SD card Supporting.

* USB Device 2.0, high speed software downloading.

* USB Host: Supporting USB Disk/USB Keyboard/Mouse expanded device etc.

Specification:

SD Card Supporting
Input Power DC 24V , Input Range: DC 18V～28V
Dimension 530mm×338mm×61mm
Download Project USB Disk/USB Device/Ethernet
Operating Temperature -10～60℃
Weight About 5300

1.Power Terminals
Pin1 DC24V 22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
Pin2 0V
Pin3 FG
2.COM1/COM3
Pin1 Rx-(B) 22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
Pin2 RxD_PLC (COM1 RS232)
Pin3 TxD_PLC (COM1 RS232)
Pin4 Tx-
Pin5 GND
Pin6 Rx+(A)
Pin7 RxD_PLC(COM3 RS232)
Pin8 TXD_PLC(COM3 RS232)
Pin9 Tx+
3.COM2/COM4
Pin1 Rx-(B) 22 Inch Multi Touch Capacitive Screen HIM TFT LCD Full HD High Resolution
Pin2 RxD_PLC (COM2 RS232)
Pin3 TxD_PLC (COM2 RS232)
Pin4 Tx-
Pin5 GND
Pin6 Rx+(A)
Pin7 RxD_PLC(COM4 RS232)
Pin8 TXD_PLC(COM4 RS232)
Pin9 Tx+
