22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
Specifications
Brand Name :
FLEXEM
Model Number :
FE5220-B
Certification :
CE
Place of Origin :
Shenzhen
MOQ :
Negotiable
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
5000 pcs/week
Delivery Time :
1-7 business days after payment confirmed
Packaging Details :
Carton
Display :
22'' TFT LCD,full HD,wide view
Resolution :
1920×1080
Power Down Allowed :
<5mS
Operating Temperature :
-10~60℃
Dimension :
530mm×338mm×61mm
Weight :
About 5300g
Description

22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution

* Audio optional.

* Projected capacitive, multi-touch Glass+Glass touch screen.

* 22 inch 1920*1080 IPS LCD, high brightness, high contrast ratio, full viewing angle.
* Aluminum panel, metal frame, exquisite and metallic appearance.
* Spray coating treatment and applicable to various harsh environment.

Colors 16-bit Colors
SD Card Supporting
Power Consumption <20W
Brightless 250cd/㎡
Download Project USB Disk/USB Device/Ethernet
Input Power ProtectionPower DC 24V, Input Range:DC18V~28V

1.Power Terminals
Pin1 DC24V 22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
Pin2 0V
Pin3 FG
2.COM1/COM3
Pin1 Rx-(B) 22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
Pin2 RxD_PLC (COM1 RS232)
Pin3 TxD_PLC (COM1 RS232)
Pin4 Tx-
Pin5 GND
Pin6 Rx+(A)
Pin7 RxD_PLC(COM3 RS232)
Pin8 TXD_PLC(COM3 RS232)
Pin9 Tx+
3.COM2/COM4
Pin1 Rx-(B) 22 Inch Industrial Touch Screen HMI With Full Viewing Angle 920×1080 High Resolution
Pin2 RxD_PLC (COM2 RS232)
Pin3 TxD_PLC (COM2 RS232)
Pin4 Tx-
Pin5 GND
Pin6 Rx+(A)
Pin7 RxD_PLC(COM4 RS232)
Pin8 TXD_PLC(COM4 RS232)
Pin9 Tx+
