Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard
Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard
Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard
Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard
Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard
Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard
Specifications
Brand Name :
HBYIQI
Model Number :
HB-TS-3-80L （A\B\C\D)
Certification :
ISO-9001
Place of Origin :
China
MOQ :
1SET
Price :
Negotiation
Payment Terms :
T/T
Delivery Time :
15 days
Packaging Details :
International Standard Package
Volume :
80L
Chamber Quantity :
3 Boxes
Heating Rate :
RT to 180℃ for approx 30min
Cooling Rate :
RT to -70℃ for approx 60min
A Type Range :
-20℃~ 150℃ or Customization
B Type Range :
-40℃~ 150℃ or Customization
C Type Range :
-50℃~ 150℃ or Customization
D Type Range :
-60℃~ 150℃ or Customization
Description

Three-Box Programmable Thermal Shock Test Chamber 80L

Brand: HBYIQI

Equipment Name: 80L Three-box Programmable Thermal Shock Test Machine

Relevant standards or equivalent requirements:

Complies with the following tests in national standards such as GB, GJB, ISO, IEC, ANSI, ASME, ASTM, JIS, BS, DIN, NF, UNI, TNAI, AS, BDSI, CAS, CA, COSQC, S., CSA, CSK, CSN, DGN, DGNT, DS, ELOT, E.S., ESI, GS, ICONTEC, INAPI, INEN, IOS, IRAM, IR, ISIRI, ITINTEC, IS, JS.S, JUS:

  • High-temperature test
  • Low-temperature test
  • Temperature Shock test
Application:

The thermal shock test chamber is a device used to simulate climatic environments. It is applicable to aerospace products, information electronic instruments and meters, automobiles, new energy, materials, electrical and electronic products, and various electronic components. It can test their tolerance and reliability in an environment with rapid extreme temperature changes, check various performance indicators of products, and simulate in advance the chemical changes and physical damages caused by different extreme environments. It can also accelerate product screening: by exposing products to extreme temperature environments in a short time, defective components or materials can be screened out. It is an essential test equipment for research and development, production, and quality control.

Technical Parameter

Model HB-TS-3-80L
(A/B/C/D)
Volume 80L
Inner Box Dimensions (cm)

W50*D40*H40
Outer Box Dimensions (cm)

W155*D195*H210
Impact Temperature Range

Type A: - 20°C to 150°C

Type B: - 40°C to 150°C

Type C: - 50°C to 150°C

Type D: - 60°C to 150°C
(Other temperature ranges are available upon customization)
High - temperature Chamber Temperature Range +60°C to +180°C
Heating Rate From room temperature (RT) to + 180°C in about 30min
Low - temperature Chamber Temperature Range 0°C to -40°C / 0°C to -70°C
Cooling Rate From room temperature (RT) to - 70°C in about 60min
Test Area High - temperature Exposure Temperature Range +60°C to +180°C
Low - temperature Exposure Temperature Range 0 to (-20)(-40)(-50)(-60)°C
Temperature Resolution 0.01°C
Temperature Fluctuation ±1°C
Temperature Deviation ±2°C (when < 150°C), ±3°C (when > 150°C)
Damper Switching Time ≤10s
Room-temperature Exhaust Time 0-5min
Temperature Recovery Time ≤5min
Test Exposure Time Requirement ≥30min
Impact Time 0-999H (settable)
Cycle Period 1-999 times (settable)
Control System PLC balanced temperature - regulated programmable control system
Language Supports Chinese and English
Refrigeration System Adopts well - known brand compressors and well - known refrigeration system accessories
Heating System Adopts nickel - chromium alloy electric heating wires
Protection Devices Leakage protection, short - circuit protection, over - temperature protection, phase - loss protection, compressor over - pressure protection, and fault alarm system.
Shelves Standard configuration: 2 pieces (more available upon customization)
Wiring Hole Ø50mm/1
Voltage (V) 380V
Power (KW) According to the design
Weight (kg) To be confirmed before shipment
Others Custom-sized orders are accepted

​Equipment Detail Display

Main Interface:

Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard

Three-Chamber Temperature Shock Curve Diagram

Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard

Test Mode:

Three Chamber Programmable Thermal Shock Test Equipment 80L GB GJB ISO Standard

For more inquiries, please contact HBYIQI directly. Thanks.
