Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Lithium Ion Battery Materials Testing Equipment Precision Gas Transmission Rate Tester
Specifications
Brand Name :
HBYIQI
Model Number :
HB-TQY-01
Certification :
ISO-9001
Place of Origin :
China
MOQ :
1SET
Price :
Negotiation
Payment Terms :
T/T
Delivery Time :
15 days
Packaging Details :
International Standard Package
Control Method :
PLC
Time Measurement Range :
30~10000S
Gas Source :
0.3~0.6mpa
Aperture Size :
Φ9.05mm or Φ28.6 ± 0.1mm
Description

Battery Materials Testing Equipment Gas Transmission Rate Tester Lithium-ion Separator


Brand: HBYIQI


Equipment Name: Gas Transmission Rate Tester


Standard basis: GB/T 36363-2018 Polyolefin Separator for Lithium-ion Batteries


Application: Gas transmission rate tester is suitable for testing the air permeability of lithium battery separators. Under a constant pressure differential of 1.21 kPa, it tests the time required for 100ml of air to pass through an area of 6.45cm² of the separator.


Technical Parameter

Equipment Model

HB-TQY-01

Control Method

 PLC

Time Measurement Range

30-10000s

Resolution

0.1s/100ml

Differential Pressure Range

0-3KPa

Precision

±0.1kPa
Test Differential Pressure

1.21kpa

Specimen Size

≥50mm*50mm

Aperture Size

 Φ9.05mm or Φ28.6 ± 0.1m

Test Area

6.45cm²
Machine Dimension

400*350*480mm

Power Supply

220V 50Hz

Power

 100W

Gas Source

0.3-0.6 mpa

Weight

28kg

Working Environment

0 ℃-40 ℃/≤ 70%RH (No Condensation)


If you want to know more detail about this equipment, don't hesitate to contact with us.

Welcome to your inquiry.
