50L×3 Supercritical Fluid CO2 Extraction Machine
50L×3 Supercritical Fluid CO2 Extraction Machine
Specifications
Brand Name :
50L×3 SCE Machine
Model Number :
SCE 50L-3-750
Certification :
ASME CE PED
Place of Origin :
Zunyi City China
MOQ :
1sets
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 sets per year
Delivery Time :
90 days
Packaging Details :
Metal frame & skin package
Extractors :
60L 750bar，3sets
Separators :
30L 200bar，2sets
Pressure :
~750bar
Temperature :
~85℃
Flow :
600L/h
Power :
180kw
Capacity :
150-200kg/24h
Area :
120m2
Height :
6m
Material :
The part in contact with CO2 and water is 304 stainless steel
Description

50L×3 Natural Astaxanthin Supercritical CO2 Extraction Machine

Device Description:
The supercritical CO2 fluid extraction(SCFE) machine can effectively extract Pure Natural Astaxanthin from Algae.
1, The SCFE technology is widely used in pharmaceutical, cosmetics, food, health products, new materials and
other fields.
2, The SCFE machine is a high-pressure systematic device which changes the CO2 between its gas, liquid
and supercritical state for extraction and separation of materials and for process of system circulation.
3, The extractor cover of this plant uses hydraulic pressure quick opening structure.
4, The max-working extraction pressure of the equipment is 700bar, max-working extaction temperature is 70℃,and
the effective volume of the material barrel is 400L.
5, The rubber and plastic foam material are used on all pressure vessels and pressure pipes to keep temperature,
outside is thin stainless steel, which will make our device beauty.
6, The extract, separate pressure and temperature can be automatic and remote controlled by PLC.
