Specifications
Brand Name :
TT
Model Number :
TT-2
Certification :
ISO9001:2015
Place of Origin :
Anping China
MOQ :
50m2
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500M2 Per Day
Delivery Time :
3-5Days,Also Depend On the Quantity
Packaging Details :
Packing Suitable For Export,Also Depend On Customar Decide
Application :
Industrial
Bearing Bar Pitch :
30mm, 40mm, 50mm, Etc
Grating Standard :
YB/T4001.1-2007
Product Category :
Industrial Steel Grating
Bearing Bar Type :
Serrated
Product Name :
Customized Thickness and Bar Spacing Industrial Steel Grating
Load Bearing Capacity :
Heavy Duty
Texture :
Stainless Steel
Description

product material Raw materials of steel grid plate are: flat steel, twist steel, pattern plate.

The steel grid plate is an open steel member which is composed of bearing flat steel and cross bar according to certain spacing and fixed by welding or pressure lock. The transverse bar is generally made of twisted square steel, round steel or flat steel, and the material is divided into carbon steel and stainless steel.

Production method of steel grid plate:

The pressure welded steel grid plate is made of load flat steel and cross bar arranged according to certain spacing longitude and latitude, using 200 tons of hydraulic resistance welding automatic equipment to weld into the original plate, through cutting, opening, packaging and other processes.

Load flat steel spacing: the center distance between two adjacent load flat steel, commonly used 30MM, 40MM two.

Bar spacing: The center spacing of two adjacent bars is usually 50MM and 100MM.

Type Welded steel grating,pressure-locked,socket-welding
Steel flat size 20*3,25*3,25*5,30*3,30*4,30*5,32*3,32*5.....45*5mm
Beraing bar pitch 12.5,15,20,25,30,35,40,50mm
Cross bar pitch 38,50,80,100mm
material Low carbon steel,stainless steel,aluminium
Surface treatment Untreated,hot galvanized,painted

standards

China:YB/T 4001.1-2007

USA:ANSI/NAAMM(MBG531-88)

UK:BS4592-1987

Australia:AS 1657-1985

Slip-Resistant Steel Grating for Ramps and Inclines: Ensuring Safe PassageSlip-Resistant Steel Grating for Ramps and Inclines: Ensuring Safe Passage

special tailor-made
In addition, the steel grid can also be customized according to the specific use environment and requirements, such as different specifications, different surface treatment methods, etc., to meet the diverse needs of different customers.
