Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Metallurgy Building Steel Grid Plate Grating Trench Cover
Specifications
Brand Name :
TT
Model Number :
TT-2
Certification :
ISO9001:2015
Place of Origin :
Anping China
MOQ :
50m2
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500M2 Per Day
Delivery Time :
3-5Days,Also Depend On the Quantity
Packaging Details :
Packing Suitable For Export,Also Depend On Customar Decide
Application :
Industrial
Bearing Bar Pitch :
30mm, 40mm, 50mm, Etc
Grating Standard :
YB/T4001.1-2007
Product Category :
Industrial Steel Grating
Bearing Bar Type :
Serrated
Product Name :
Customized Thickness and Bar Spacing Industrial Steel Grating
Load Bearing Capacity :
Heavy Duty
Texture :
Stainless Steel
Description

product material Raw materials of steel grid plate are: flat steel, twist steel, pattern plate.

The steel grid plate is an open steel member which is composed of bearing flat steel and cross bar according to certain spacing and fixed by welding or pressure lock. The transverse bar is generally made of twisted square steel, round steel or flat steel, and the material is divided into carbon steel and stainless steel.

Production method of steel grid plate:

The pressure welded steel grid plate is made of load flat steel and cross bar arranged according to certain spacing longitude and latitude, using 200 tons of hydraulic resistance welding automatic equipment to weld into the original plate, through cutting, opening, packaging and other processes.

Load flat steel spacing: the center distance between two adjacent load flat steel, commonly used 30MM, 40MM two.

Bar spacing: The center spacing of two adjacent bars is usually 50MM and 100MM.

Drainage steel grating cover Drainage ditch material

Steel,Low carbon steel,stainless steel&Q235,A36,SS304,SS316L,

S235JR
Surface treatment Black, hot dipped galvanized, paint
Bearing bar width*thickness 25x3,25x4,30x3,30x4,30x5,32x5,40x5,50x5,.....75x10mm
Bearing bar pitch

12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40, 41, 60mm.

US standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x 1/4",

1 1/4"x 1/4", 1 1/2"x 1/4" etc.
Bearing bar shape

Plain Style Steel Grating, Serrated Style Steel Grating and I

Bar Type Steel Grating.
Drainage steel grating cover drainage ditch standard

China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),

UK: BS4592-1987, Australia: AS1657-1985, Japan: JJS.
Cross bar shape round,twisted,bar shape
Cross bar pitch 38,50,76,100,101.6mm
Galvanizing standard US: ASTM (A123), CN: GB/T13912, UK: BS729
Market distribution America45%,Europe26%,Middle east38%,Other place27%

service aim
Carefully produce every piece of steel grid plate, emphasizing the principle of integrity first. For the needs of customers to do their best to meet, to ensure that everyone buy the rest of the peace of mind.Carefully select raw materials, for each processing procedure of the product are strictly checked to ensure that the products sent to the hands of customers are durable and beautiful appearance so that more people choose our products

item Galvanized Stainless Fence Drainage Channel Serrated Steel Bar Steel Grating
Warranty More than 5 years
Surface galvanized
Style Plain sheet,Serrated sheet,I type sheet
Usage Industrial platform, Corridor laying, Ditch cover plate, Fence, etc
Bearing bar pitch Custom:12.5-90mm Routine use:20mm 30mm 40mm
Cross bar pitch Custom:22-100mm Routine use:50mm 100mm
Thickness Custom:3-10mm Routine use:3mm 4mm 5mm
Weld way Automatic pressure resistance welding
