32x5mm Heavy Duty Welded Steel Grating Industrial Metal Plug Walkways Floor Walk
32x5mm Heavy Duty Welded Steel Grating Industrial Metal Plug Walkways Floor Walk
32x5mm Heavy Duty Welded Steel Grating Industrial Metal Plug Walkways Floor Walk
32x5mm Heavy Duty Welded Steel Grating Industrial Metal Plug Walkways Floor Walk
Specifications
Brand Name :
Zhuote
Model Number :
354/30/100
Certification :
ISO9001-2015
Place of Origin :
Hebei
MOQ :
55 piece
Price :
Can discuss
Payment Terms :
L/C, T/T
Supply Ability :
1000 Square meters/day
Delivery Time :
11 work days
Packaging Details :
Steel belt packaging
Material :
Steel, Q235, SS316
Surface treatment :
Hot Dipped Galvanized, Galvanized, painting, hot dip galvanized, painted
Type :
Plain Bar Grating, Serrated Bar Grating, Plain, Serrated
Color :
Silver, Silver or as your requirement, green, black, White
Thickness :
6mm, 3mm
Length :
max 6000mm, 0.8m, Customer's Demand, 2m
Keywords :
steel grating, swimming pool drain grating
Height :
25/30/32/35/40mm, customized, 25~40mm
Description

32x5mm Industrial Metal Plug Walkways Floor Walk Heavy Duty Steel Grating​

Product Description:
The press welded steel grating ,requested by the customers,is made of load flat steel bar and cross bars,placed horizontally and
vertically ,and at an equal pitch apart ,by welding with 200-ton hydraulic resistance automatic welding equipment ,then
cutting,punching and banding ends.

Loading bearing steel bar pitch:pitch between the two neighboring load bearing steel bars is 30mm,or40mm.

Cross bar pitch:pitch between two neighboring cross bars is usually 50mm or 100mm,Special specification ca be done according to
your request.

Welded steel grating:

when selecting a bar grating product, consider Welded Steel Grating first. Usually our most economical products, they provide a comfortable walking surface with nearly 80 percent open area. This, combined with the positive welded cross bar/bearing bar intersection, make these products our most popular. Manufactured from ASTM A-1011 carbon steel, welded gratings are recommended for nearly all industrial flooring applications.

No. Item

Description
1 Bearing Bar

25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc

I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc

US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'', 1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1 1/2''x1/8'' etc
2 Bearing Bar Pitch

12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc

US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
3 Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
4 Material Grade

ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400,

Mild steel & Low carbon steel, etc
5 Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
6 Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar
7 Standard

China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),

UK: BS4592-1987, Australia: AS1657-1985,

Germany: DIN24537-1-2006, Japan: JIS

32x5mm Heavy Duty Welded Steel Grating Industrial Metal Plug Walkways Floor Walk32x5mm Heavy Duty Welded Steel Grating Industrial Metal Plug Walkways Floor Walk32x5mm Heavy Duty Welded Steel Grating Industrial Metal Plug Walkways Floor Walk

Panel packing:
<1>Plastic film at the bottom to avoid the panel be destroyed
<2>4 metal corners to ensure the panel strong and uniform
<3>wood plate at the top of pallet to keep the under panel
<4>pallet tube size:40*80mm tubes at the botom vertical position


Fence post packing:
<1>plastic cap cover onto the post
<2>plastic film +metal pallet for fence pot

Accessories packing:
<1>stainless steel nuts and screws install with clips
<2>5 sets clips load into one plastic bag
<3>12 bags into one carton box
FAQ

Q: Why to choose us? Any advantages?

A: The answer is Yes.

1) The most preferential price:Our offer will be reasonable, our price will be cheaper in the

same quality.

2) Customize: We can make the product as your request, specification,size and quality can meet

your request.

3) Mix order: We accept mix order, different specification and small quantity order.

4) Quality assurance:We have professional quality testing team.They will test the products before shipment.

5) After-sales service:Any question is welcome.

Q: Can I order one piece for sample to test the quality?
A: Yes, We recommend to check the sample before order.

Q: May I have your catalogue and price list for trial order in MOQ quantity?
A: All our products were shown on , please have a detailed looking and choose the interested products in our site.

Q: If I want cheaper quality, can you produce?
A: Yes, just send us your quality details, such as the material, what cheaper parts instead, etc, we will do that as your request and calculate the price.

Q: If I order big quantity, what's the good price?
A: Please send the details enquiry to us, such as the products specification,quantity and other requirements. We will make the most competitive quotation to you as soon as possible.
