Sawdust Cocoshell Fired High Pressure Steam Boiler ASME Certification
Sawdust Cocoshell Fired High Pressure Steam Boiler ASME Certification
Specifications
Brand Name :
Henan Yuanda Boiler
Model Number :
SZL model
Certification :
ISO 9001,CE,ASME
Place of Origin :
Henan,China
MOQ :
1 Set
Price :
Depends on boiler model
Payment Terms :
D/P, D/A, L/C, T/T
Supply Ability :
150 sets per month
Delivery Time :
3 weeks after payment
Packaging Details :
Wood box for boiler accessories.
Product :
Sawdust Cocoshell Fired Industrial Steam Boiler High Pressure Boiler
Installation :
Package Boiler
Steam Boiler Suit Fuel :
Coal, Biomass
Steam Boiler Grate Type :
Chain Grate ,travelling grate
Type :
Natural circulation
Design Efficiency :
> 80%
Pressure :
1.25 mPA 1.6mPA
Burning Style :
Chamber Combustion biomass sawdust Boiler
Description

Sawdust Cocoshell Fired Industrial Steam Boiler High Pressure Boiler

Boiler introduction

SZL series product has a double-drum offset hearth (D-type layout), great apply for biomass fuel, environmental protection and energy conservation, and is a key promoted product of national energy-saving projects.Honor of this boiler:
1.National Scientific and Technological Progress Second Prize
2.Singapore New Product Expo Golden Lion Award

Boiler design advantages

1. Design the cyclone chamber structure in furnace,high temperature flue gas through high - speed rotation, mixing combustion, dust separation, and thus achieve the effect of dust removal, energy saving and environmental protection
2. Large furnace volume,strong adaptability for coal, available for all kinds of biomass as fuel
3. Large heating surface , boost pressure quickly, sufficient output,low energy consumption
4. Fast assembly from factory, short installation time

Technical parameter of SZL biomass boiler

Model Capacity Pressure Rated Feed water temp. Rated steam temp. Active grate area Boiler heating area Boiler efficiency Fuel consump.
t/h Mpa ℃ ℃ ㎡ ㎡ % kg/h
SZH2-1.25/2.5-AII 2 1.25/2.5 20 194/226 2.78 69.5 81 225/228
SZH4-1.25/2.5-AII 4 1.25/2.5 20 194/226 4.5 119.2 81 450/462
SZL2-1.25/2.5-AII 2 1.25/2.5 20 194/226 3.1 64.6 81.6 223/227
SZL4-1.25/2.5-AII 4 1.25/2.5 20 194/226 4.6 115.3 81.6 447/453
SZL6-1.25/2.5-AII 6 1.25/2.5 20 194/226 7.3 136.3 81.6 671/684
SZL8-1.25/2.5-AII 8 1.25/2.5 20 194/226 10.4 173 81.8 781/803
SZL10-1.25/2.5-AII 10 1.25/2.5 20 194/226 11.8 233 82 1113/1127
SZL15-1.25/2.5-AII 15 1.25/2.5 20 194/226 17.7 307.3 82.3 1663/1686
SZL20-1.25/2.5-AII 20 1.25/2.5 20 194/226 20.8 725.2 82.3 2218/2246

Biomass fuel

Biomass is the form of energy that solar energy is stored in the form of chemical energy in biomass. Usually including wood, forest waste, agricultural waste (wheat straw, rice straw, bean curd, peanut shell, corn cob , Bagasse, etc.), aquatic plants, oil plants, urban and industrial organic waste, animal feces and so on.

Economic choice---Yuanda Boiler

1. Safe and reliable, low cost running boiler

2. Enough steam output and high quality steam.
3. Long life span(More than 30 years ).
4. Intelligent and fully automatic.
5. Easy inspection and maintenance.
