Horizontal Fire Tube Boiler 6 Ton Water Fire 6000 kg Red Color TUV Certification
Horizontal Fire Tube Boiler 6 Ton Water Fire 6000 kg Red Color TUV Certification
Specifications
Brand Name :
Yuanda
Model Number :
Biomass boiler
Certification :
ISO 9001,SGS,TUV
Place of Origin :
Henan,China
MOQ :
1 set
Price :
Be negotiable
Payment Terms :
D/P, D/A, L/C, T/T, Western Union
Supply Ability :
120 sets monthly
Delivery Time :
15-25 days after payment
Packaging Details :
Professional transport cooperate company.
Boiler type :
steam output biomass boiler
Boiler color :
red
Rated working pressure :
1.25MPa,1.6MPa
Design fuel :
paddy,bagasse
Boielr structure :
Large burning space
Steam temprature :
194°c
Rated steam capacity for steam boilers :
6000 kg
Product name :
Horizontal Type Biomass Steam Boiler 6Ton Water Fire Tube Boiler
Description

Horizontal Type Biomass Steam Boiler 6Ton Water Fire Tube Boiler

Boiler structure features

1. The hearth is designed with a cyclone reburning chamber, and high temperature fume achieves the effects of primary dedusting energy conservation and environmental protection through high speed revolution, mixed combustion and dust separation.
2. With a hearth with large volume and strong coal adaptability, it can use various biomasses as the fuel.
3. It has large heating surface, rapid boost, sufficient capacity, rapid warming and low energy consumption.

Technical Parameter Table for reference

Model capacity pressure Feed water temperature Rated steam temperature Boiler efficiency Dimension Delivery Mode
t/h Mpa ℃ ℃ % mm
SZH2-1.25/2.5-AII 2 1.25/2.5 20 194/226 81 4850×2690×3468 Package Bolier
SZH4-1.25/2.5-AII 4 1.25/2.5 20 194/226 81 5450×3040×3468
SZL2-1.25/2.5-AII 2 1.25/2.5 20 194/226 81.6 5960×2960×3468
SZL4-1.25/2.5-AII 4 1.25/2.5 20 194/226 81.6 6510×3130×3468
SZL6-1.25/2.5-AII 6 1.25/2.5 20 194/226 81.6 7830×3346×3468
SZL8-1.25/2.5-AII 8 1.25/2.5 20 194/226 81.8 8200×3346×3468
SZL10-1.25/2.5-AII 10 1.25/2.5 20 194/226 82 8500×3346×3482 Assembled Boiler
SZL15-1.25/2.5-AII 15 1.25/2.5 20 194/226 82.3 9583×3400×3550
SZL20-1.25/2.5-AII 20 1.25/2.5 20 194/226 82.3 11600×3460×3520

SZL biomass boiler advantages

(1) High effiency and energy saving.
(2) Enough steam output and high quality steam.
(3) Safe and reliable.
(4) Long life span (More than 20 years ).
(5) Intelligent and fully automatic.
(6) Easy inspection and maintenance.

Application fields

1. Food industry: wine factory, brewery, sauce making, break making,etc.

2. Wood processing industry

3. Textile indsutry

4. Sugar mills

5. Rice mills
