6 Ton Straw Dust Industrial Biomass Boiler Conveyor Feeding Running
6 Ton Straw Dust Industrial Biomass Boiler Conveyor Feeding Running
Specifications
Brand Name :
Yuanda
Model Number :
Biomass boiler
Certification :
ISO 9001,SGS,TUV
Place of Origin :
Henan,China
MOQ :
1 set
Price :
Up to boiler capacity
Payment Terms :
D/P, D/A, L/C, T/T, Western Union
Supply Ability :
150 sets monthly
Delivery Time :
about 20 working days after payment
Packaging Details :
Professional transport cooperate company.
Boiler type :
steam boilers
Boiler color :
silver, grey
Rated working pressure :
15bar
Design fuel :
sawdust, wood pellets
Boielr structure :
water tube boilers
Steam temprature :
194°c
Rated steam capacity for steam boilers :
6ton/hr
Product name :
6Ton Straw Dust Biomass Steam Boiler Conveyor Feeding Running Boiler
Description

6Ton Straw Dust Biomass Steam Boiler Conveyor Feeding Running Boiler

SZL Chain Grate Stoke Double Drum Coal Fired Steam Boiler

SZL is a horizontal biomass/coal fired steam boiler, with superior structure design and high thermal efficiency, innter ''A'' 'D'' type sturcture steam boiler. Biomass fuel can be coconut shell, bagasse, ricehusk, coconut shell, etc.


1. Sufficient output, safe and reliable operation
2. The design of cyclone reburning chamber in furnace resulted in the decrease of dust contained in the flue gas. the gas emission concentration shall meet the requirements of grade A environmental protection area.
3. Big furnace design activities, coal, fuel wood, wood scraps, etc all can be used as fuel.

Technical Parameter Table

Model capacity pressure Feed temp Rated steam temp Active grate area Boiler heating area Boiler efficiency Weight Dimension
t/h Mpa ℃ ℃ ㎡ ㎡ % Ton mm
SZH2-1.25/2.5-AII 2 1.25/2.5 20 194/226 2.78 69.5 81 17/18.5 4850×2690×3468
SZH4-1.25/2.5-AII 4 1.25/2.5 20 194/226 4.5 119.2 81 22/24.8 5450×3040×3468
SZL2-1.25/2.5-AII 2 1.25/2.5 20 194/226 3.1 64.6 81.6 20/25 5960×2960×3468
SZL4-1.25/2.5-AII 4 1.25/2.5 20 194/226 4.6 115.3 81.6 28/29 6510×3130×3468
SZL6-1.25/2.5-AII 6 1.25/2.5 20 194/226 7.3 136.3 81.6 38/42 7830×3346×3468
SZL8-1.25/2.5-AII 8 1.25/2.5 20 194/226 10.4 173 81.8 52 8200×3346×3468
SZL10-1.25/2.5-AII 10 1.25/2.5 20 194/226 11.8 233 82 68 8500×3346×3482
SZL15-1.25/2.5-AII 15 1.25/2.5 20 194/226 17.7 307.3 82.3 30 9583×3400×3550
SZL20-1.25/2.5-AII 20 1.25/2.5 20 194/226 20.8 725.2 82.3 40 11600×3460×3520

For know more about the boiler details, contact us.

Boiler work advantages

1. Large furnace volume, strong adaptability for coal, available for all kinds of biomass as fuel.
2. Large heating surface , boost pressure quickly, sufficient output,low energy consumption.
3. Fast assembly from factory, short installation time.

4. High boiler thermal efficiency, easy operation and long using life.

Boiler application fields

Food Industry---Industry steam boiler for food & beverage industry is used in the processes of distillation, sterilization, disinfect, extraction, drying, and curing, etc.

Sugar Mill---In sugar mill, steam plays a significant role for the processes of heating, gelatinization, and saccharify. The temperature needed is from about 30℃ to 80℃.

Wood Processing Industry---In wood industry, steam is significant for the processes of preservation, drying, digestion, and hot processing.
