PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms
PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms
PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms
PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms
PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms
PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms
Specifications
Brand Name :
CENO
Model Number :
PSCN042-02P4-02S-A
Certification :
CE,RoHS,UL,ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T,Paypal,Western Union
Supply Ability :
10000pcs per month
Delivery Time :
2 weeks
Packaging Details :
Carton/As request
Current & Circuits :
2 circuits * 20A; 2 circuits * Can signal
Rating Voltage :
0~100VAC/VDC
Dielectric strength :
≥300VAC@50Hz
Isolation resistance :
≥100MΩ@100VDC
Electrical noise :
≤30mΩ (50rpm)
Operating speed :
0~80rpm
Contact material :
Precious metal
Materials :
FR-4
Working temperature :
-20°C~+60°C
Working humidity :
60%
IP protection grade :
IP00
Through hole size :
Ø42mm
Outer diameter :
Ø94mm
Lead wire size & length :
As customized
Description

PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms

PSCN042-02P4-02S-A is CENO pancake slip ring with 20A current and CAN signal. The design principle of pancake slip rings is based on a simple planar sliding electrical contact mechanism. Convert traditional radial sliding friction into axial planar sliding friction, and use spring pressure and planar ring to achieve stable and reliable electrical connection. Often equipped in machines such as security and surveillance, Aerospace, test equipment or display and entertainment etc. For more information please contact us.

Features

  • Precious contact material to ensure long service life
  • Achieve multifunctional, high-density integrated transmission
  • Install easy & Free maintenance

Applications

  • Automatic machine
  • Turntable testing machine
  • Packing equipment
  • Robot arm or joint
  • Medical equipment

Optional

  • Circuit, Voltage, Current
  • Signals and data
  • Contact / Housing Materials
  • Inner / outer diameter
  • Working speed & temperature




Specification

PSCN042-02P4-02S-A Specification
Current & Circuits 2 circuits * 20A; 2 circuits * Can signal
Rating Voltage 0 ~ 100 VAC/VDC
Dielectric strength ≥300VAC@50Hz
Isolation resistance ≥100MΩ@100VDC
Contact resistance wave ≤ 30mΩ
Working temperature -20°C~+60°C
Working humidity 60 %RH
IP protection grade IP00
Operating speed 0~80rpm
Inner diameter Ø42mm
Contact material Gold to gold
Housing material FR4



Outline drawing
PCB-style Pancake Slip Ring with electric power and CAN signal for robot arms



Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

Certification

ISO9001,CE,RoHS,UL,Explosion-proof

CENO Advantage

Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.

Service CENO provides

24 hours,7days consultant service.

Mass and customized production.

Solution offerring for 360° rotation system.

Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
