Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Hybrid Slip Ring with 2 Ethernet channels
Specifications
MOQ :
1pcs
Delivery Time :
1 week
Dielectric Strength :
≥500vAC@50Hz(Power); ≥300VAC@50Hz(Signal)
Price :
Negotiable
Working Temperature :
-20℃~+60℃
Certification :
CE,RoHS,ISO9001,UL
Rotation Way :
Flange installation
Model Number :
ECN000-03120-12P-04S-02EG
Insulation Resistance :
500MΩ@500VDC(Power); 100MΩ@300VDC(Signal)
Payment Terms :
T/T,Paypal,Western Union
Working Humidity :
60%RH
Circuits & Current :
3 Circuits * 120A(72V);8 Circuits *10A(48V); 4 Circuits *1A(48V);1 Group * CAN bus; 2 Groups * Gigabit Ethernet
Rating Voltage :
0~72VAC/VDC
Lead Wire Length :
Rotor: 1500mm; Stator:1500mm
Place of Origin :
China
Working Speed :
0~30rpm
Packaging Details :
Carton/As request
Supply Ability :
500pcs per month
Protection(IP Grade) :
IP51
Brand Name :
CENO
Electrical Noise :
Max 20mΩ(50rpm)
Contact Material :
Precious Metal/Gold to gold
Housing Material :
Aluminum Alloy
Description

Hybrid Slip Ring with 2 Ethernet channels


ECN000-03120-12P-04S-02EG is CENO Hybrid Slip Ring integrates 3×120A heavy power circuits, 8×10A auxiliary power, 4×1A signal lines and 2 Ethernet channels to transmit power, control signals and high-speed data during 360° unlimited rotation. Separated power and signal cables effectively reduce electromagnetic interference. Built with anodized aluminum housing and precious metal contacts, it meets CE & RoHS standards for stable long-term heavy-duty rotary industrial operation.


Features

  • 120A heavy power
  • Power-signal isolation
  • Dual Ethernet
  • Flange mount
  • Solid shaft

Applications

  • Heavy rotary jig
  • Large rotary platform
  • Wind rotary unit
  • Power test bench
  • Heavy-duty pan-tilt

Optional

  • Custom circuits
  • Adjustable current
  • Custom wire length
  • Higher IP grade
  • Shielded wiring

Specification

ECN000-03120-12P-04S-02EG

Specification

Protection(IP Grade)

IP51

Working Humidity

60%RH

Working Temperature

-20℃~+60℃

Rating Voltage

0~72VAC/VDC

Circuits & Current

3 Circuits * 120A(72V);8 Circuits *10A(48V);

4 Circuits *1A(48V);1 Group * CAN bus;

2 Groups * Gigabit Ethernet

Dielectric Strength

≥500vAC@50Hz(Power); ≥300VAC@50Hz(Signal)

Insulation Resistance

500MΩ@500VDC(Power); 100MΩ@300VDC(Signal)

Electrical Noise

Max 20mΩ(50rpm)

Lead Wire Length

Rotor: 1500mm; Stator:1500mm

Working Speed

0~30rpm

Rotation Way

Flange installation

Contact Material

Precious Metal/Gold to gold

Housing Material

Aluminum Alloy


Outline drawing

Hybrid Slip Ring with 2 Ethernet channels


Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

Hybrid Slip Ring with 2 Ethernet channels


Certification

ISO9001,CE,RoHS,UL,Explosion-proof

Hybrid Slip Ring with 2 Ethernet channels


CENO Advantage

Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.


Service CENO provides

24 hours,7days consultant service.

Mass and customized production.

Solution offerring for 360° rotation system.


Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
