ACS580-01-033A-4 ABB Variable Frequency Inverter 380v/220v Single Phase Three Phase
ACS580-01-033A-4 ABB Variable Frequency Inverter 380v/220v Single Phase Three Phase
ACS580-01-033A-4 ABB Variable Frequency Inverter 380v/220v Single Phase Three Phase
ACS580-01-033A-4 ABB Variable Frequency Inverter 380v/220v Single Phase Three Phase
Specifications
Brand Name :
ABB
Model Number :
ACS580-01-033A-4
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
negotiation
Payment Terms :
T/T, L/C
Supply Ability :
100
Delivery Time :
5-7 days
Packaging Details :
New and Original
Power Output :
480W
Typical Ouptut :
7.5KW
Watchdog Timer :
66 MHz
Type :
380v/220v Single Phase Three Phase
Inverter Output Voltage :
3 x 230V AC
Output Frequency :
0.1-300Hz
Range :
30M
Outputfrequency :
0-400Hz
Description

ACS580-01-033A-4 ABB Variable Frequency Inverter 380v/220v Single Phase Three Phase

ACS580-01-033A-4 Description

The ACS580-01-033A-4 is a versatile, all-compatible general purpose drive (GPD) from ABB. Designed for a wide range of applications, it combines core functions, built-in application macros, and simple setup to provide reliable and energy-efficient control of AC induction motors. This model is a core component for industrial automation, offering a plug-and-play solution for applications from basic fan and pump control to more complex material handling systems.
ACS580-01-033A-4 Features
  • Effi­ciency Optim­izer:​ An embedded feature that automatically adjusts the motor flux to the optimal level, reducing motor energy losses by up to 30% in variable torque applications.
  • Built-in Application Macros:​ Pre-programmed parameter sets (e.g., for Pumps & Fans, Conveyors, Constant Speeds) simplify startup and commissioning, allowing for quick configuration without deep technical knowledge.
  • Intuitive Control Panel:​ Equipped with a multilingual, backlit Assisted Control Panel (ACP) that provides intuitive navigation, real-time status monitoring, and quick diagnostics.
  • Embedded Safety:​ Includes a standard Safe Torque Off (STO) safety function (SIL 3, PL e) to help meet safety standards and protect personnel during maintenance.
  • Robust Design:​ Features a high ingress protection (IP21) rating as standard, ensuring reliable operation in challenging industrial environments with dust and dripping liquids. An optional IP55/UL Type 12 kit is available.
  • Connectivity Ready:​ Comes with built-in Modbus RTU and integrates easily with major fieldbus systems (PROFIBUS DP, PROFINET, EtherNet/IP, etc.) via optional adapters for seamless plant integration.
ACS580-01-033A-4 Material & Applications
  • Material:​ Housed in a compact, robust metal chassis with a coated finish for corrosion resistance. Internal components include high-quality IGBT power semiconductors, an efficient heatsink, and industrial-grade PCB assemblies. The ACP features a polycarbonate faceplate.
  • Primary Applications:​ Ideal for a broad spectrum of variable speed applications, including HVAC systems (fans, pumps, cooling towers), water & wastewater treatment, material handling (conveyors, mixers), and general industrial machinery.
ACS580-01-033A-4 Key Parameters
Parameter
Specification
Model​
ACS580-01-033A-4
Product Line​
ABB ACQ580 / ACS580 General Purpose Drive
Rated Power​
33 A / 15 kW (20 HP) at 400V
Supply Voltage​
3-Phase, 380-480 V AC, 50/60 Hz
Output Voltage​
0 to Supply Voltage
Overload Capability​
110% of rated current for 60 seconds every 300 seconds (Heavy Duty), 150% for 1 second (Light Duty)
Control Characteristics​
Open Loop, scalar (V/f) and sensorless vector (DTC) control modes
Standard I/O​
2 Analog Inputs (0/4-20 mA, 0-10 V), 1 Analog Output, 4 Digital Inputs, 2 Digital Outputs, 2 Relay Outputs
Built-in Safety​
Safe Torque Off (STO) according to EN 61800-5-2, SIL 3, PL e
Enclosure Rating​
IP21 as standard. IP55/UL Type 12 with optional kit.
Communication​
Built-in Modbus RTU. Fieldbus via optional adapters (PROFIBUS, PROFINET, EtherNet/IP, etc.).
Control Panel​
Standard Assisted Control Panel (ACP) with multilingual display.
Cooling Method​
Forced air cooling
Ambient Temperature​
-15 to 50°C (5 to 122°F) without derating. Up to 55°C (131°F) with derating.

Good Service in WTL:


> We offer high quality, fast delivery, competitive price for Rosemount.


> Please send your RFQ to get the latest price.


> Normally, we will ship the items in 1-2 weeks after receive the payment.


> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.


> We have a large stock and the prices are variable, so sometimes the prices we post are not accurate. If needed, please contact us for specific prices.


Liability:

WTL is not liable for any personal injury or property damage resulting from the use of this equipment. It is

buyer's responsibility as to the safe handling & operation of this equipment and to verify equipment is

compliance to their machinery.

Our advantage Products:


【Honeywell】Module DCS / PLC


【Emerson】DeltaV Module / Servo Motor

【ABB】Input Output Module


【AB】Module / Touch Screen


【Rosemount】Pressure and Temperature Transmitter


【Yokogawa】Pressure Transmitter


【Yaskawa】Servo Drive / Servo Motor


【Mitsubishi】Servo Drive / Servo Motor


【GE】IC69 Series PLC/ Fanuc Servo Motor and Drive

(Modicon,SMC,SICK,NORGREN,Siemens etc.)
