AB 1769-IQ16 A Industrial Servo Motor -40 To +70℃ 50/60 Hz, 1 Min: 2 KV

1769-IQ16 Description

The Allen-Bradley 1769-IQ16 is a 16-Channel, 24V DC Sink/Source Input Module part of the CompactLogix 5000 and Compact I/O family. This module is designed to interface digital field devices (like sensors, switches, and push buttons) with the programmable logic controller (PLC). A key feature of the 1769-IQ16 is its universal wiring capability, meaning it can be connected to either sinking (NPN) or sourcing (PNP) field devices without requiring hardware changes, providing exceptional application flexibility. It is a high-density module that saves panel space while delivering reliable performance for industrial control applications.

1769-IQ16 Features

  1. 1.
    Universal Sink/Source Operation:​ Automatically detects the input type (sinking or sourcing), simplifying design, installation, and maintenance by eliminating the need for different module types or complex jumper settings.
  2. 2.
    High-Density Design:​ 16 points on a single module, maximizing I/O count and reducing the overall footprint of the control system.
  3. 3.
    LED Status Indicators:​ Each channel has a status LED to indicate the state (On/Off) of the input, facilitating quick diagnostics and troubleshooting at the module.
  4. 4.
    Removable Terminal Block:​ Features a user-removable screw terminal block for easy wiring and module replacement, which minimizes downtime during maintenance.
  5. 5.
    Seamless Integration:​ Integrates natively with the Studio 5000 Logix Designer environment for easy configuration and programming within the Rockwell Automation ecosystem.
  6. 6.
    CompactBus Interface:​ Uses a built-in connector for connecting to adjacent modules, eliminating the need for separate bus cables and reducing installation time.

1769-IQ16 Material and Typical Applications

  • •
    Materials:​ The module features a robust plastic housing with a metal connector for the CompactBus. The terminal blocks are typically made of high-quality, heat-resistant thermoplastic. The internal circuitry is designed for industrial electromagnetic noise immunity.
  • •
    Primary Applications:​ This digital input module is used in a vast range of industrial automation applications, including:
    • •
      Machine Control: Reading the status of limit switches, photoelectric sensors, and push buttons.
    • •
      Material Handling Systems: Monitoring sensors on conveyors and palletizers.
    • •
      Packaging Machinery: Interfacing with various detection sensors.
    • •
      Automated Assembly Lines: Receiving signals from part presence sensors and safety interlocks.

1769-IQ16 Important Parameters

The key specifications for the 1769-IQ16 are detailed in the table below.
Parameter
Specification
Product Type​
16-Channel Digital DC Input Module
Part Number​
1769-IQ16
I/O Points​
16 points, grouped in 4 points per common (4 commons total)
Input Voltage Range​
10-31 V DC (sink or source)
Nominal Input Voltage​
24V DC
On-State Voltage​
≤ 10V DC
Off-State Voltage​
≤ 5V DC
Input Current (Nominal)​
3.5 mA @ 24V DC
Point Update Time​
0.5 ms typical for all points
Backplane Current Draw​
85 mA @ 5V DC
Isolation Voltage​
50V continuous (Field-side to logic-side)
Terminal Type​
Removable 20-pin screw terminal block
Status Indicators​
Power (OK LED) and per-channel status (I/O LEDs)
Compatible Controllers​
CompactLogix 5370 L1/L2/L3, CompactLogix 5380, CompactLogix 1769-L3x
Software Configuration​
Studio 5000 Logix Designer
