AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
Specifications
Brand Name :
MITSUBISHI
Model Number :
AJ55TB2-16R
Certification :
CE
Place of Origin :
Japan
MOQ :
1
Price :
Contact
Payment Terms :
T/T, Western Union,paypal
Packaging Details :
NEW AND ORIGINAL
Supply Ability :
100
Delivery Time :
3-5DAYS
Brand :
MITSUBISHI
Modenl number :
AJ55TB2-16R
Country of origin :
Japan
program capacity :
8 k steps
basic operation processing speed (LD instruction) :
0.12 μs
input :
100 to 240 V AC
output :
5 V DC/3 A
Type :
Redundant Power Supply Module
Description

Redundant Power Supply Module Mitsubishi Universal model AJ55TB2-16R

AJ55TB2-16R Description

The AJ55TB2-16R is a high-performance remote relay output module designed for industrial fieldbus distributed control systems. It acts as a network slave station, receiving control commands from the main controller via fieldbus communication, and provides 16-channel mechanical relay contact outputs to drive various industrial actuators, solenoid valves, contactors and indicator devices. Featuring compact structure, built-in isolation circuit and reliable relay switch performance, it is widely applied in decentralized automation scenarios requiring dry contact signal output.

AJ55TB2-16R Key Features

  • 16 Independent Relay Output Channels:16 isolated mechanical relay points for flexible multi-path load control.
  • Dry Contact Relay Output:Form A normally open contact output, suitable for AC and DC mixed load circuits.
  • Built-in Optocoupler Isolation:Complete electrical isolation between internal communication circuit and external relay contacts to suppress interference.
  • Fieldbus Network Compatibility:Supports mainstream industrial fieldbus protocols, occupying few network stations to save address resources.
  • LED Status Indication:Front panel power, network communication and individual channel status LEDs for quick on-site diagnosis.
  • Industrial Grade Relay:Long mechanical and electrical service life, stable switching under rated load for long-term continuous operation.
  • Screw Terminal Wiring:Standard screw terminal block for firm wiring, anti-loosening and suitable for vibration environment.
  • DIN Rail Mounting:Standard DIN rail installation, easy to assemble, replace and expand in control cabinets.
  • Overvoltage & Surge Suppression:Built-in absorption circuit to protect relay contacts and rear-stage loads from voltage impact.
  • Wide Environmental Adaptability:Withstands temperature fluctuation, humidity and mechanical vibration in factory workshop conditions.

AJ55TB2-16R Materials & Applications

Materials

  • Housing:Flame-retardant high-strength engineering plastic with UL94 V-0 grade, good insulation and impact resistance.
  • Circuit Board:High-temperature FR-4 glass epoxy multilayer PCB with SMT industrial components.
  • Relay Unit:Industrial electromagnetic relay with alloy contacts, oxidation resistance and stable conduction performance.
  • Terminals:Nickel-plated brass screw terminals, corrosion resistant and reliable wire connection.
  • Internal Components:Optocoupler isolators, surge absorption elements, voltage regulation chips and filter circuits.
  • Indicators:Long-life high-brightness LED lamps for clear status display.

Typical Applications

  • Factory Automation:Control of solenoid valves, air cylinders, hydraulic valves, intermediate relays and signal lights.
  • Packaging Machinery:Actuator control, sealing and positioning switch signal output.
  • Material Handling:Conveyor system start-stop control, sorting mechanism and diverter action output.
  • Machine Tools:Cooling system, lubrication system and safety interlock loop control.
  • Water Treatment:Water pump, fan and electric valve switch control.
  • Textile & Printing Machinery:Action control of transmission mechanism and executive components.
  • Building Automation:Air conditioning fan, lighting and pipeline valve remote control.
  • General Industrial Control:Dry contact signal switching and interlock control of various automation equipment.

AJ55TB2-16R Important Parameters

Parameter Specification
Model Number AJ55TB2-16R
Product Type Fieldbus Remote Relay Output Module
Output Channel 16 channels mechanical relay output
Relay Contact Type Form A (Normally Open)
Rated Switching Voltage 240V AC / 30V DC
Rated Switching Current 2A per point (resistive load)
Min Switching Load 5V DC, 10mA
Mechanical Life 20,000,000 operations
Electrical Life 100,000 operations (rated load)
Isolation Method Optocoupler isolation between network and output
Communication Mode Industrial fieldbus slave station
Occupied Station 1 station
Power Supply 24V DC (19.2～26.4V DC)
Internal Current Consumption Approx. 60mA @ 24V DC
Connection Type Screw terminal block
Mounting Standard DIN rail
Operating Temperature 0°C ~ +55°C
Storage Temperature -20°C ~ +75°C
Operating Humidity 10%～90% RH (non-condensing)
Vibration Resistance 5～150 Hz, 9.8 m/s²
Shock Resistance 147 m/s², 11ms duration
Insulation Resistance ≥20 MΩ (500V DC)
Withstand Voltage 1500V AC 1 minute
Protection Grade IP20
Indicators Power, Network, Channel status LED
Certifications CE, UL/cUL, RoHS compliant

AJ55TB2-16R Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A
