ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
ALJ3000-3004 Rubber Shock Absorber with 55-60 Shore A Hardness and Steel+Rubber Construction for 500-3500HZ Frequency Range
Specifications
Material :
Steel+Rubber
Color :
Natural Color
Payment Terms :
L/C,D/P,T/T,Western Union
Rubber Hardness :
55-60 shore A
name :
rubber shock absorber
Brand Name :
3A Rubber
Model Number :
ALJ3000-3004
Certification :
ISO9001
Place of Origin :
China
MOQ :
10
Price :
USD25.00/piece
Supply Ability :
100000piece/month
Delivery Time :
5-8days
Packaging Details :
packing in cartons
Description
ALJ3000-3004 OEM Rubber Shock Absorber, Anti Vibration Rubber Mounts
Product Overview

The ALJ3000-3004 rubber mounting is a bell-type shock absorber featuring professional technology and unique formulation. Manufactured using full sets of injection moulds without mould lines, this product eliminates mould costs. The design includes a round cap with female screw made from high-quality zinc-coated metal sheet, a bottom support metal sheet with 2 sockets, and high-quality NBR or NR rubber in the middle with full adhesive bonding between rubber and metal components.

Key Features
  • Effective vibration absorption in both axial and lateral pressure applications
  • Ideal for generators, engines, motors, and similar systems
  • Working frequency range: 500-3500HZ and 1500-3500HZ mounting
  • Enhanced safety with special safety lock design in the middle
  • Reliable and durable construction with strong rubber-to-metal bonding
  • Small rubber compression with higher load capacity
Applications

Suitable for anti-vibration and shock absorption in various industrial applications including generators, engines, motors, compressors, pumps, refrigerators, and other mechanical systems.

Specifications
Material Blue zinc-plated metal + rubber
Rubber Type NR, NBR (default is NR 60 shore A)
Quality Grade Industrial grade
Color Natural galvanized color
Top Design Metal cap with screw thread
Middle Component High tensile rubber
Bottom Design Metal seat with grooves
Surface Finish Smooth
Tensile Strength 8-12 MPa
Hardness 40, 60+/-5 shore A
Elongation 350%
Density 1.4 g/cm³
Working Temperature -40°C to +120°C
Working Frequency 500-3500 HZ
Size Options Standard without mould cost
Packing Cartons and crates
Customization OEM & customized sizes available upon agreement
Ordering Information: When placing an order, please confirm the quantity, product code number, or provide your technical drawings.
