Specifications
Brand Name :
3A Rubber
Model Number :
3A2006
Certification :
ISO9001
Place of Origin :
China
MOQ :
10pieces
Price :
USD0.35/piece
Payment Terms :
L/C,D/P,T/T,Western Union,
Supply Ability :
1000000pieces/month
Delivery Time :
7-15days
Packaging Details :
packing in cartons
Material :
Virgin TPU
Color :
Yellow
Tensile Strength :
30Mpa
Hardness :
93Shore A
Elongation :
560%
Density :
1.15g/cm3
Size :
Standard Size
Packing :
in Cartons
Description
1.15g/cm³ Density Polyurethane Coupling Standard Size Virgin TPU Material
Product Description
93 Shore A Yellow Joong Ang Coupling, Joong Ang Element, Joong Ang Spider for Vessel Industrial Applications
1.15g/cm3 Density 30Mpa Tensile Strength 560% Elongation Polyurethane Coupling Standard Size Virgin TPU Material 1.15g/cm3 Density 30Mpa Tensile Strength 560% Elongation Polyurethane Coupling Standard Size Virgin TPU Material 1.15g/cm3 Density 30Mpa Tensile Strength 560% Elongation Polyurethane Coupling Standard Size Virgin TPU Material
Size Material Hardness OD(mm) ID(mm) Thickness H(mm) Thickness H1(mm) Lamella Qty
CR0050/MS0511 Yellow TPU 93Shore A 25 9.5/12.5 10 11.2 6
CR0070/MS0714 Yellow TPU 93Shore A 35 13.7/19.0 13 15 6
CR0010/MS1119 Yellow TPU 93Shore A 48 17.0/23.5 14 16 6
CR0020/MS1424 Yellow TPU 93Shore A 58 22.0/28.8 15 17 6
CR2035A/MS1928 Yellow TPU 93Shore A 66.5 26.0/32.0 17 19 6
CR2035/MS1938 Yellow TPU 93Shore A 78 30.4/40.0 19 20 6
CR3545/MS2845 Yellow TPU 93Shore A 98 43.0/50.0 20 24 6
CR4560/MS3860 Yellow TPU 93Shore A 116 55.0/62.0 21 25 6
CR6070/MS4275 Yellow TPU 93Shore A 131 62.0/70.5 26 28 6
CR7080/MS6510 Yellow TPU 93Shore A 156 60.0/85.0 34 38 6
Material Characteristics
Polyurethane elastomer is a synthetic polymer material combining properties of rubber and plastic, offering:
  • Wide hardness range (Shore A10-D80) with excellent elasticity
  • Exceptional tensile strength and load capacity exceeding standard rubber
  • Superior wear resistance (3-5 times better than rubber)
  • Excellent oil resistance and low affinity with non-polar mineral oils
  • Outstanding resistance to oxygen, ozone, and radiation
  • Superior vibration absorption and damping properties
  • Good low-temperature performance and machinability
Product Specifications
Materials: TPU, CSM/SBR, NBR, nylon
Colors: Yellow, red, purple, green, black, beige
Surface: Smooth
Tensile Strength: 8-55Mpa
Hardness: 70-98Shore A
Elongation: 400%-650%
Density: 1.25g/cm³
Elasticity Impact: >25%
Tear Strength: 35-155KN/m
Akron Abrasion Loss: <0.05cm³/1.61km
Compression Set (22h*70°C): <10%
Working Temperature: Up to 120°C
Standard Sizes Available
Polyurethane Couplings:
GR14, GR19, GR24, GR28, GR38, GR42, GR48, GR55, GR65, GR75, GR90, GR100, GR110, GR125, GR140, GR160, GR180
GS14, GS19, GS24, GS28, GS38, GS42, GS48, GS55, GS65, GS75, GS90, GS100, GS110, GS125, GS140, GS160, GS180
MT1-MT13, ML1-ML13, MH45-MH200, HRC70-HRC280
L35-L276, FALK-R 10R-80R, SBT T40-T210
Joong Ang CR0050-CR7080, MS0511-MS6510
D14-D65, 5H-11H
Rubber Couplings:
Hb80-Hb315, HRC70-HRC280, L35-L225
NM50-NM265, NOR-MEX168-10 to 265-10
FCL1#-FCL8#, FCL90-FCL630
Gear 3J-14J, Hytre 4H-11H, Tyre F40-F160
SBT T75-T210, FCLpin #1-#8, GR42-GR75
Nylon Couplings:
NL1-NL10, M28-M65
Additional Information
Packaging: Cartons
Customization: OEM and custom sizes available
Special Supply: All types of steel couplings for various industrial applications
Note: Please confirm type, size number and quantity when enquiring
