White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
White 100% Virgin PTFE Tubing Industrial Grade 20Mpa Tensile Strength
Specifications
Brand Name :
3Arubber
Model Number :
3A3003
Certification :
ROHS/FCC/SGS
Place of Origin :
China
MOQ :
10pieces
Price :
neogation
Payment Terms :
L/C, T/T, Western Union,Paypal
Supply Ability :
100000 kgs per month
Delivery Time :
10 working days after received your payment
Packaging Details :
packed in cartons
Material :
100% Virgin PTFE Material
Produced :
Moulded
Quality :
industrial grade,food grade
Color :
white,blak,brown
Surface :
smooth
Tensile Strength :
20Mpa
Elongation :
200%
Density :
2.1-2.3g/cm³
Hardness :
55shore D
Description

PTFE Tube, PTFE Hose, PTFE Tubing, PTFE Pipe, PTFE Tube, Tube Hose Made with 100% Virgin PTFE

Physical character: Made by moulded or extruded with high quality polytetrafluoroethylene(PTFE) material. It is the best polymer material of chemical resistance in all knows plastic material. With excellent characteristics of corrosion resistance, weathering resistance, dielectric properties and lowest coefficient of fraction in all know solid materials in a wide range of practicable temperature from -180° C - +260° C and a wax-like surface to which anything hardly sticks. Ø 2-9mm is made by paste extruded, Ø 10-50mm is made by RAM extruded, Ø 50-300mm is made by moulded. It has the best electrical properties of all plastics. The electrical insulation used under various kinds of frequency, the seal liner of various kinds of corrosively medium, anti-sticking materials, lubrication material.

Specifications:

Material 100% virgin PTFE, 50% virgin PTFE
Filling Graphite, carbon or bronze
Quality Premium grade, commercial grade
Color White, black
Surface Smooth
Tensile strength 20Mpa
Hardness 55+/-5shore D
Elongation at break 200%
Density 2.1-2.3G/cm3
Break down voltage 10KV/mm
Temp resist -180° C - +260° C
Size for soft PTFE tube Ø 2-25mm X Ø 4-30mm X 10-50m length
Size for extrude PTFE tube Ø 24-104mm X Ø 28-110mm X 4000mm length
Size for moulded PTFE tube Ø 20-200mm X Ø 40-400mm X 10-300mm length



Black available to fill 3% graphite or 10% carbon
***when you enquiry, pls confirm the color, size and quantity***
