High Quality Silicone Rubber Sheet with 3600mm Width, FDA Compliance, and Excellent UV Resistance for Solar Vacuum Press Laminator
High Quality Silicone Rubber Sheet with 3600mm Width, FDA Compliance, and Excellent UV Resistance for Solar Vacuum Press Laminator
High Quality Silicone Rubber Sheet with 3600mm Width, FDA Compliance, and Excellent UV Resistance for Solar Vacuum Press Laminator
High Quality Silicone Rubber Sheet with 3600mm Width, FDA Compliance, and Excellent UV Resistance for Solar Vacuum Press Laminator
Specifications
Brand Name :
3Arubber
Model Number :
3A1002
Certification :
ROHS/FCC/SGS
Place of Origin :
China
MOQ :
100kgs
Price :
negotation
Payment Terms :
T/T,L/C,Paypal,Western Union,D/P
Supply Ability :
100000kgs per month
Delivery Time :
10-20 working day after recieveed your payment
Packaging Details :
packed in rolls and pallets
Surface :
smooth/smooth,
Reinforce :
insert 1 ply fabric
Tensible Strengh :
7-12Mpa
Hardness :
40,50,60,70,80+/-5shore a
Elongation :
350%-720%
Density :
1.25+/-0.05g/cm3 (1.5g/cm3 for Fire-Resis
Thickness :
0.1-50mm
Width :
3.6m max
Length :
1-100m
Ply Material :
aramid fabric or glassfiber fabric
Usage :
silicone pad
Fda Compliance :
Yes
Others :
As Per Buyer's Drawing
Uv Resistance :
Excellent
Sample :
Available
Aging Resistance :
Excellent
Process :
Extrusion
Chemical Resistance :
Excellent
Port :
Shanghai port and others
Finish :
Smooth or Textured finish
Function :
oil resistance/waterproof
Description
High-Performance Silicone Rubber Sheet for Solar Vacuum Press Laminators
Premium quality silicone rubber sheets specifically engineered for solar vacuum press laminators and hot press applications. Manufactured using advanced drum-type vulcanizing technology to deliver superior performance and reliability.
Product Features
  • Manufactured using high-grade HTV silicone rubber or liquid silicone
  • Available in industrial, food, medical, and FDA grade postcured options
  • Excellent resistance to aging, ozone, heat, oil, solvents, and corrosion
  • Non-toxic, odorless, and pollution-free composition
  • Operating temperature range: -60°C to +260°C (momentary maximum 300°C)
  • High stability and reliability with non-sticky surface properties
  • Available in widths up to 3600mm without joints
Technical Specifications
Parameter Specifications
Material 100% virgin HTV silicone rubber or liquid silicone
Grade Industrial grade, food grade, medical grade, FDA grade postcured
Quality High tear resistant, middle tear resistant
Color Transparent, translucent, dark red, black, milk white, grey, blue, etc.
Surface Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric
Reinforcement Insert 1 PLY fabric
Tensile Strength 7-12 MPa
Hardness 10, 20, 30, 40, 50, 60, 70, 80+/-5 shore A
Elongation 350%-720%
Density 1.25-1.50 g/cm³
Tear Strength 26-42 N/mm
Working Temperature -60°C to +260°C (momentary 300°C)
Thickness 0.1-50 mm
Width 0.1-3.6 m
Length 1-50 m
Standard Sizes
Transparent, 8 shore A
1.2mm x 330mm x 330mm, 1.7mm x 330mm x 330mm, 2.2mm x 330mm x 330mm, 2.5mm x 330mm x 330mm, 3.0mm x 330mm x 330mm
Translucent, 10 shore A
3.0mm x 330mm x 330mm
Translucent, 45-75 shore A
0.1-2.0mm x 0.5-1.1m x 25/50/100/200m
0.5-6.0mm x 0.5-1.2m x 10/20m
1.0-30.0mm x 0.5/1.0/1.2m x 10/20m
1.0-6.0mm x 1.5-3.8m x 10/20m
Custom OEM sizes available upon agreement
Application Notes
Press Compatibility:
German silicone for "+" and "-" press on wooden PVC vacuum laminators
Chinese silicone for "-" press only on wooden PVC vacuum laminators
Special FDA grade silicone rubber sheets with postcure treatment and antistatic silicone sheets with fire-resistant properties available in black color with smooth surface.
Important: When requesting a quote, please specify application, color, hardness, size, and quantity requirements.
