Durable Silicone Rubber Sheet for Vacuum Press Laminator with High Tensile Strength 7-12Mpa and Customizable Size and Color
Durable Silicone Rubber Sheet for Vacuum Press Laminator with High Tensile Strength 7-12Mpa and Customizable Size and Color
Durable Silicone Rubber Sheet for Vacuum Press Laminator with High Tensile Strength 7-12Mpa and Customizable Size and Color
Durable Silicone Rubber Sheet for Vacuum Press Laminator with High Tensile Strength 7-12Mpa and Customizable Size and Color
Durable Silicone Rubber Sheet for Vacuum Press Laminator with High Tensile Strength 7-12Mpa and Customizable Size and Color
Durable Silicone Rubber Sheet for Vacuum Press Laminator with High Tensile Strength 7-12Mpa and Customizable Size and Color
Specifications
Brand Name :
3Arubber
Model Number :
3A1002
Certification :
ROHS/FCC/SGS
Place of Origin :
China
MOQ :
100kgs
Price :
negotation
Payment Terms :
T/T,L/C,Paypal,Western Union
Supply Ability :
100000kgs per month
Delivery Time :
10-20 working day after recieveed your payment
Packaging Details :
packed in rolls and pallets
Surface :
smooth/smooth,
Reinforce :
insert 1 ply fabric
Tensible Strengh :
7-12Mpa
Hardness :
40,50,60,70,80+/-5shore a
Elongation :
350%-720%
Density :
.25+/-0.05g/cm3 (1.5g/cm3 for Fire-Resis
Thickness :
0.1-50mm
Width :
1.5m-3.6m
Length :
1-100m
Customization :
Size, Color, Printing
Grade :
industrial grade without smell
Size :
1.5-3.6m X 1-20m
Lead Time :
7-15 days
Tensile Strength :
7-12 MPa
Top Material :
Virgin Silicone with Rough Surface
Upper Rubber Layer :
1.0, 2.0, 3.0mm,4.5mm,6.0mm
Resistance To :
Chemicals, Oils, and UV
Description
Silicone Rubber Sheet For Vacuum Press Laminator
High-quality silicone rubber sheets designed for vacuum press laminators, offering exceptional durability and versatility for industrial applications.
Product Overview
Our premium silicone rubber sheets are manufactured using advanced drum-type vulcanizing press technology, ensuring superior quality and performance. We overcome the limitations of traditional ROTOCURE vulcanizing machines by delivering products with smooth surfaces, precise thickness tolerance, and seamless construction without visible joints.
Key Features
  • Manufactured using high-quality HTV silicone rubber or liquid silicone
  • Available in industrial grade, food grade, medical grade, and FDA grade postcured options
  • Excellent resistance to aging, ozone, heat, oil, solvents, and corrosion
  • Non-toxic, odorless, and pollution-free material
  • Operates effectively in temperatures from -60°C to +260°C (momentary maximum 300°C)
  • Super-wide manufacturing capability up to 4000mm width
  • Seamless construction with maximum 3600mm width without joints
Technical Specifications
Material 100% virgin HTV silicone rubber or liquid silicone
Grade Industrial grade, food grade, medical grade, FDA grade postcured
Quality High tear resistant, middle tear resistant
Color Transparent, translucent, dark red, black, milk white, grey, blue, etc.
Surface Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric
Reinforce Insert 1 PLY fabric
Tensile Strength 7-12Mpa
Hardness 10, 20, 30, 40, 50, 60, 70, 80+/-5 shore A
Elongation 350%-720%
Density 1.25-1.50g/cm³
Tear Strength 26-42N/mm
Working Temperature -60°C - +260°C (momentary 300°C)
Thickness 0.1-50mm
Width 0.1-3.6m
Length 1-50m
Standard Sizes
Transparent, 8 shore A
1.2mm x 330mm x 330mm, 1.7mm x 330mm x 330mm, 2.2mm x 330mm x 330mm, 2.5mm x 330mm x 330mm, 3.0mm x 330mm x 330mm
Translucent, 10 shore A
3.0mm x 330mm x 330mm
Translucent, 45-75 shore A
0.1-2.0mm x 0.5-1.1m x 25/50/100/200m
0.5-6.0mm x 0.5-1.2m x 10/20m
1.0-30.0mm x 0.5/1.0/1.2m x 10/20m
1.0-6.0mm x 1.5-3.8m x 10/20m
Custom OEM sizes available upon agreement
Application Information
Press Compatibility:
German silicone: Compatible with "+" and "-" press on wooden PVC vacuum laminator
Chinese silicone: Compatible with "-" press only on wooden PVC vacuum laminator
Special Options:
FDA grade silicone rubber sheet with postcure
Antistatic silicone sheet with fire-resistant properties (black color, smooth surface)
Applications
  • PVC vacuum laminating press
  • Wooden door vacuum laminating press
  • Glass vacuum laminating press
  • Solar vacuum laminating press
  • Hot laminating press
  • Card laminating press
  • Rubber seal gaskets
Important: When requesting a quote, please specify your application requirements, color preference, hardness specification, dimensions, and quantity.
