High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
High Temperature 100% Virgin PTFE Gasket Tape FDA Grade for Industrial Sealing
Specifications
Length :
6-50m
quality :
FDA grade
Color :
white, yellow, red
working temperature :
-150°C ~ +250°C
Width :
10-100mm
Brand Name :
3A Rubber
Model Number :
3A3006
Certification :
ROHS/FCC/SGS
Place of Origin :
China
MOQ :
1000rolls
Price :
negotiation
Payment Terms :
T/T,L/C,Paypal,Western Union
Supply Ability :
10000kgs per month
Delivery Time :
10 working days after received your payment
Packaging Details :
Packed in cartons
Thickness :
0.075-0.25mm
Material :
PTFE expand
density :
0.20-1.60g/cm3
Description
High Temperature 100% Virgin PTFE Gasket Tape In White, Red, Green, Blue
Product Overview

100% virgin PTFE unsintered tape, PTFE high temperature thread tape

PTFE resin is first molded into work-blank and then skived. The PTFE resin skived sheet tape are highly dielectric, chemical resistant and not aging. They have a wide range of operation temperature.

Applications
  • Lining, sealing and oilless lubricating material
  • Dielectric at any frequencies
  • Capacitor dielectric
  • Wire isolation
  • Electrical instrument isolation
Product Specifications
Item Thickness (mm) Thickness Allowance Width (mm) Width Allowance Length (m)
High-density 0.030~0.100 ±10% 30~90 ±0.3 ≥10
Semi-density 0.050~0.100 ±10% 60~90 ±0.3 ≥5
Common 0.050~0.500 ±10% 60~90 ±0.3 ≥5
Technical Data
Technical Data Unit High-density Semi-density Common
Tensile strength ≥0.01 Mpa ≥30 ≥20 ≥10
Elongation at rupture % ≥30 ≥60 ≥100
1MHZ dielectric loss Tangent ≥0.01 2.5x10⁴ - -
1MHZ dielectric constant 1.8~2.2 - -
DC breakdown voltage (normal temperature) Kv/mm 200 60 30
