Specifications
Brand Name :
3A Rubber
Model Number :
3A5001
Certification :
ROHS/FCC/SGS
Place of Origin :
China
MOQ :
100kgs
Price :
neogation
Payment Terms :
L/C,T/T,Western Union,Paypal
Supply Ability :
100000pieces per month
Delivery Time :
5-10days after received your payment
Packaging Details :
packing in rolls
material :
pure natural rubber or NR/SBR
quality :
industrial grade, food grade
color :
black, white, brown, beige, red, green etc.
surface :
smooth/smooth, smooth/impression fabric, double impression fabric
tensile strength :
2-24Mpa
hardness :
35, 40, 50, 60, 70, 80+/-5shore A
elongation :
170%-760%
density :
1.05-1.70g/cm3
working temperature :
-35°C - +85°C
Description
Red Natural Rubber Sheet / Gum Rubber Sheet
High-performance natural rubber sheets designed for truck lining and drinking water lining applications. Manufactured using premium natural rubber with excellent elasticity, durability, and safety properties.
Product Overview
Our natural rubber sheets, also known as gum rubber sheets or para rubber sheets, are produced using ROTOCURE vulcanizing press or plain vulcanizing press technology. These sheets feature medium hardness with high tensile strength, exceptional elongation properties, superior abrasion resistance, and excellent elasticity. The material is completely safe and non-toxic with no odor.
Key Features
  • Made from high-quality natural rubber (NR) sourced from rubber trees
  • Available in industrial grade and food grade quality
  • Excellent tensile strength and elongation properties
  • Superior abrasion resistance and elasticity
  • Safe, non-toxic, and odor-free composition
  • Suitable for temperatures from -35°C to +85°C
  • Available in various colors and surface finishes
Technical Specifications
Material Pure natural rubber or NR/SBR blend
Quality Grades Industrial grade, Food grade
Available Colors Black, white, brown, beige, red, green, and more
Surface Options Smooth/smooth, Smooth/impression fabric, Double impression fabric
Tensile Strength 2-24 MPa
Hardness 35, 40, 50, 60, 70, 80 ±5 Shore A
Elongation 170%-760%
Density 1.05-1.70 g/cm³
Working Temperature -35°C to +85°C
Thickness Range 1.0-50.0 mm
Width Range 0.1-3.6 m
Length Range 1.0-20 m
Reinforcement 1-3 PLY fabric insertion available
Natural Rubber Lining Sheet Specifications
Construction Top: Cured natural rubber (red or black)
Bottom: Uncured neoprene rubber (light yellow)
Quality Grades Industrial grade, Food grade
Surface Smooth/smooth
Tensile Strength 13-18 MPa
Hardness 35, 40, 65 ±5 Shore A
Elongation 400%-650%
Density 1.05-1.15 g/cm³
Working Temperature -35°C to +85°C
Thickness Range 1.0-25.4 mm
Width Range 1-1.5 m
Length Range 10-20 m
Applications
Ideal for punching various seals, gaskets, lining applications, and rubber membranes. Specifically designed for truck lining, drinking water lining, and PVC vacuum laminating press applications.
Manufacturing Process
Sheets with 1-6mm thickness are manufactured using ROTOCURE vulcanizing press technology, resulting in a shiny surface finish. Thicker sheets (7-80mm) are produced using conventional vulcanizing presses to achieve higher thickness requirements.
Important: When requesting a quote, please specify the required tensile strength, hardness, color, dimensions, and quantity to ensure accurate pricing and delivery.
Product Images
Food Grade Natural Rubber Sheet with High Tensile Strength and Wide Temperature Range for Industrial Applications Food Grade Natural Rubber Sheet with High Tensile Strength and Wide Temperature Range for Industrial Applications Food Grade Natural Rubber Sheet with High Tensile Strength and Wide Temperature Range for Industrial Applications
