316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
Specifications
Certification :
CE,RoHS
MOQ :
1
Price :
50
Model NO. :
BH93420-III
Output Signal :
4-20mA or RS485
IP Rating :
IP68
Net Weight :
0.3kg
Diaphragm Material :
316L Stainless Steel
Accuracy :
0.25%, 0.5%
Cable Material :
PE, PU, PTFE
Measurement Range :
0~10m…400m
Pressure Type :
Gauge Pressure, Absolute Pressure, Sealed Pressure
Overload Capacity :
≤ 2X rated range
Operating Temperature :
-20~80ºC
Storage Temperature :
-30~100ºC
Housing Material :
Cast aluminum, 1Cr18Ni9Ti
Insulation Resistance :
>=100MΩ@100VDC
Explosion-proof Rating :
ExiaIICT6
Description
BH93420-III Water Level Transmitter
High-precision silicon pressure sensor transducer designed for oil and water level testing applications, featuring advanced leak detection capabilities.
Product Overview
The BH93420-III oil level sensor utilizes a highly precise Piezoresistive diffused silicon pressure sensor to measure static pressure, which directly correlates to water level. This measurement is converted into standard signal output through amplification circuitry, establishing a linear relationship between output signal and liquid level for precise and accurate water level measurement.
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing 316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing 316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
Key Features
  • Split-type design for easy on-site wiring and calibration
  • Integrated LED display for clear readings
  • Explosion-proof rating: ExiaIICT6
  • High protection rating: IP68
  • Multiple cable options: PE, PU, PTFE
Applications
  • Compatible with 316L stainless steel and non-corrosive liquids
  • Monitoring water levels in sewage, industrial and municipal water systems, water tanks, wells, rivers, seawater, and lakes
  • Diesel, fuel, and other oil tank level monitoring
Performance Parameters
Measurement Range 0~10m…400m
Pressure Type Gauge Pressure, Absolute Pressure, Sealed Pressure
Overload ≤ 2X rated range
Accuracy @ 25ºC ±0.25% (Typ.) ±0.5% (Max.)
Repeatability ±0.03% (Typ.) ±0.05%FS (Max.)
Hysteresis ±0.03% (Typ.) ±0.05%FS (Max.)
Long-Term Stability ±0.15%F.S/year (Max.)
Zero Temperature Drift ±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa)
Span Temperature Drift ±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa)
Compensation Temperature 0-50ºC (0-1m . 0-2m); 0-70ºC
Operating Temperature -20~80ºC
Storage Temperature -30~100ºC
Vibration 10g,55Hz ~ 2kHz
Shock 100g
Housing Material Cast aluminum, 1Cr18Ni9Ti
Diaphragm Material 316L Stainless Steel
Insulation Resistance >=100MΩ@100VDC
Explosion-proof Rating ExiaIICT6
Protection Rating IP68
O-Ring Seal Fluoro rubber
Weight ~1.5Kg (without cable)
Cable Material Polyethylene, Polyurethane, PTFE cable
Output Signal Supply Voltage Output Type
4~20mA 15~30VDC 2/3/4 wire
RS485 Communication Protocol 4 wire
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
Outline Construction
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
Electrical Connection
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
Selection Examples
316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing 316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing 316L Stainless Steel IP68 Waterproof Liquid Level Transmitter with 4-20mA Output for Oil and Water Testing
Ordering Information
Important Considerations
  • Ensure measured medium compatibility with product components
  • Specify density of the measured medium
  • For strong electromagnetic or radio frequency interference, provide details and indicate in order
  • Install lightning protection devices and ensure reliable grounding for optimal performance
Order Guide
BH93420 Code Outline Construction
III Liquid level transmitter with 2088 housing
Measurement Range 0~10m…400m
Code Power Supply
D1 24VDC
Code Output Signal
S1 4~20mADC
S2 RS485
Code Electrical Connection
B5 2088 with display
B6 3051A
Code Pressure Type
G Gauge Pressure
A Absolute Pressure
S Sealed Reference Pressure
Code Material
01 304 Stainless Steel
02 316L Stainless Steel
Code Cable Material
C1 PE
C2 PU
C3 PTFE
Frequently Asked Questions
What are the features of your pressure sensor transmitters?
High precision, durability, and excellent performance. Customization available.
Can I customize special specifications?
Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM services.
What is your production capacity?
Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters per month, capable of meeting large-scale orders. Contact our sales team in advance for production and delivery scheduling.
What's the typical delivery period?
5-8 working days for standard models. Customized products may vary.
How are the products priced? Any discounts?
Competitive pricing with discounts for bulk orders or long-term partners.
What is the warranty of your products? And after-sales service?
24-month warranty after shipment. Our after-sales team responds within 24 hours, with remote PC network instruction always available.
